Figure 4-2 Network Ports on the Back of the Oracle Exalytics In-Memory
Machine X3-4
Figure 4-3 Network Ports on the Back of the Oracle Exalytics In-Memory
Machine X2-4
In Figure 4-3 and Figure 4-2, the four 10/100/1000 Gb Ethernet ports located on the
rear of the Oracle Exalytics In-Memory Machine are shown in a red circle of dashed
line. They are named
NET 0
Note:
Although you can use any of these Gb Ethernet ports, Oracle recommends
that you use
NET 0
The ILOM 10/100 Ethernet port is shown in a blue circle of solid line. This port is
named .
NET MGT
, , , and
NET 1 NET 2 NET 3
.
Overview of Network Ports
.
Chapter 4
4-3
