Replacing An Ssd; Remove The Ssd - HPE ProLiant MicroServer Gen10 Maintenance And Service Manual

Replacing an SSD

Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 25.
5. Remove the SSD on page 39.
6. Install the new SSD.
7. Install the chassis cover on page 29.
8. Connect all peripheral cables to the server.
9. Connect the power cord to the server power jack, and then to the AC source.
10. Power up the server on page 30.

Remove the SSD

Prerequisites
Before you perform this procedure, make sure that you have the following items available:
• T-10 Torx screwdriver
• T-15 Torx screwdriver
Procedure
1. Disconnect the SSD power and SATA cables from the SSD.
Replacing an SSD 39
