Replacing an SFF drive

Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4. Remove the front bezel on page 22.
5. Remove the SFF drive on page 33.
6. Install the new SFF drive.
7. Install the front bezel on page 29.
8. Connect all peripheral cables to the server.
9. Connect the power cord to the server power jack, and then to the AC source.
10. Power up the server on page 30.

Remove the SFF drive

Prerequisites
Before you perform this procedure, make sure that you have a T-10 Torx screwdriver available.
Procedure
1. To disengage the drive converter tray, press the drive latch.
2. Slide the converter tray out of the drive bay.
3. Remove the screws on the bottom of the converter tray.
