For more information about battery replacement or proper disposal, contact an authorized reseller or an
authorized service provider.

Replacing the system board assembly

Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 25.
5. If installed, remove the internal USB device.
6. Remove the system board assembly on page 67.
7. Install the new system board assembly.
8. If removed, install the internal USB device.
9. Install the chassis cover on page 29.
10. Connect all peripheral cables to the server.
11. Connect the power cord to the server power jack, and then to the AC source.
12. Power up the server on page 30.
13. Re-enter the system serial and SKU numbers.

Remove the system board assembly

Prerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
