Replacing an LFF drive

Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4. Remove the front bezel on page 22.
5. Remove the LFF drive on page 31.
6. Install the new LFF drive.
7. Install the front bezel on page 29.
8. Connect all peripheral cables to the server.
9. Connect the power cord to the server power jack, and then to the AC source.
10. Power up the server on page 30.

Remove the LFF drive

Prerequisites
Before you perform this procedure, make sure that you have a T-15 Torx screwdriver available.
Procedure
1. To disengage the drive, press the drive latch.
2. Slide the drive out of the drive bay.
3. Remove the screws from both sides of the drive.
Replacing an LFF drive 31
