Replacing a DIMM

IMPORTANT: Before replacing a DIMM, expansion board, or any other circuit board component due
to a perceived hardware error, verify that the component is firmly seated in the slot. Do not bend or
flex circuit boards when reseating components.
Procedure
1. Power down the server on page 22.
2. Disconnect the power cord from the AC source, and then from the server.
3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 25.
5. Remove the DIMM on page 51.
6. Install the new DIMM.
7. Install the chassis cover on page 29.
8. Connect all peripheral cables to the server.
9. Connect the power cord to the server power jack, and then to the AC source.
10. Power up the server on page 30.

Remove the DIMM

Procedure
1. Open the DIMM slot latches.
2. Remove the DIMM.
Replacing a DIMM 51
