Four Bay Non-Hot-Plug Drive Cable Assembly Spare Part; System Board Assembly Spare Parts; System Battery Spare Part; Dimm Spare Parts - HPE ProLiant MicroServer Gen10 Maintenance And Service Manual

Four bay non-hot-plug drive cable assembly spare part

Customer self repair on page 6: Mandatory
Description
Four bay non-hot-plug drive cable assembly
For more information on the removal and replacement procedures, see Replacing the non-hot-plug
drive cable assembly on page 47.

System board assembly spare parts

Customer self repair on page 6: Mandatory
The system board assembly spare includes the system board attached to the tray, with the heatsink and
the rear USB EMI shield installed.
Description
System board assembly with AMD Opteron X3216 APU
System board assembly with AMD Opteron X3418 APU
System board assembly with AMD Opteron X3421 APU
For more information on the removal and replacement procedures, see Replacing the system board
assembly on page 67.

System battery spare part

Customer self repair on page 6: Mandatory
Description
3.3-V, 220-mAh lithium battery coin
For more information on the removal and replacement procedures, see System battery replacement on
page 65.

DIMM spare parts

Customer self repair on page 6: Mandatory
Description
8 GB, single-rank x8 PC4-2400T-E
16 GB, dual-rank x8 PC4-2400T-E
For more information on the removal and replacement procedures, see Replacing a DIMM on page 51.

Power supply spare part

Customer self repair on page 6: Mandatory
Spare part number
874741-001
Spare part number
319603-001
Spare part number
869537-001
869538-001
Four bay non-hot-plug drive cable assembly spare part
Spare part number
874737-001
P07949-001
874738-001
17
