HPE ProLiant MicroServer Gen10 Maintenance And Service Manual page 45

3. Disconnect all peripheral cables from the server.
4. Remove the chassis cover on page 25.
5. Disconnect the SSD SATA cable.
6. Connect the new SSD SATA cable.
7. Install the chassis cover on page 28.
8. Connect all peripheral cables to the server.
9. Connect the power cord to the server power jack, and then to the AC source.
10. Power up the server on page 30.
Disconnect the SSD SATA cable
Procedure
1. Open the cable tie securing the SSD SATA cable.
2. Disconnect the SATA cable from the SATA connector, and then pull the cable out of the left side
chassis opening.
3. Disconnect the SATA cable from the SSD.
Disconnect the SSD SATA cable 45
