General

Overview of the The conventional TPS/i welding system with internal wirefeeding hose is available in two
conventional TPS different variants:
/i welding system -
with internal wire- -
feeding hose -
The variants differ in terms of the possible wirefeeding distance.
(4)
max.
max.
15 m
8 m
(3)
(2)
A B
(1)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
Variant A: with an unreeling wirefeeder (4)
Variant B: with an unreeling wirefeeder (2)
Variant C: with two unreeling wirefeeders (2) and (4)
(4)
max. 15 m
max. 15 m
(14)
C
(13)
(12)
Wire drum
Unreeling wirefeeder, for example WF 30 R REEL 2R
Wirefeeding hose
B only: Unreeling wirefeeder, for example WF 30 R REEL 2R
Interconnecting hosepack
Media splitter, for example SB 500i R
"QuickConnect" option
Torch hosepack
CrashBox and robot flange
WF 25i Robacta Drive
Robot welding torch
Service station, for example Robacta TX/i
Trolley or upright console
Cooling unit, for example CU 1400i Pro
Power source, for example TPS 320i
(5) (6)
max. 15 m
(7)
(8)
(9)
(10)
(11)
