Installing the CrashBox Drive /i PAP on the robot

Installing the
1
1
CrashBox on the
robot
1
2
3
4
90
Observe the torques when fitting the robot
flange:
Thread dimen- Max. tightening torque
sion for screws of strength
class 8.8
M4 3.3 Nm
M5 6.5 Nm
M6 11.3 Nm
M8 27.3 Nm
M10 54 Nm
M12 93 Nm
