SplitBox SB 500i R

Device concept

The SplitBox (SB) 500i R, SB 500i R / L and SB 500i R PAP devices bring together the
welding media for automated MIG/MAG welding and have been specially designed for
mounting onto the robot. Two versions of the devices are available:
-
-

Proper use

The device is designed exclusively for bringing together the welding media in automated
MIG/MAG welding applications in conjunction with Fronius system components. Any use
above and beyond this purpose is deemed improper. The manufacturer shall not be held
liable for any damage arising from such usage.
Utilisation in accordance with the intended purpose also comprises:
-
-
-

Safety

R = for applications in which the hosepack is externally mounted on the robot
PAP = for applications in which the hosepack is mounted in the robot arm
carefully reading these operating instructions
following all the instructions and safety rules in these operating instructions
performing all the stipulated inspection and maintenance work
WARNING! Incorrect operation or shoddy workmanship can cause serious injury
or damage. All work described in this document must only be carried out by
trained and qualified personnel. All functions described in this document must
only be used by trained and qualified personnel. Do not carry out any of the work
or use any of the functions described until you have fully read and understood the
following documents:
- this document
- all the operating instructions for the system components, especially the safe-
ty rules
31
