SB 500i R, R left variant, PAP

SB 500i R, R left
Supply voltage
variant, PAP
Nominal current
Welding current at 10 min/40°C (104°F)
Maximum shielding gas pressure
Coolant
Maximum coolant pressure
Degree of protection
Mark of conformity
Dimensions l x w x h
Weight
*) D.C. = duty cycle
24 V DC / 60 V DC
0.5 A / 0.8 A
40% D.C.* 650 A
60% D.C.* 600 A
100% D.C.* 500 A
7 bar
101.53 psi.
Original Fronius
5 bar
72.53 psi.
IP 43
CE, CSA
658 x 282 x 362 mm
25.91 x 11.10 x 14.25 in.
3.6 kg
7.9 Ib.
