WF 25i REEL R /4R, WF 30i REEL R /2R

Safety

Device concept

The unreeling wirefeeder is an extra drive unit for ensuring constant and precision wire-
feeding over large wirefeeding distances between the welding wire drum and the robot
wirefeeder.
While in operation, the unreeling wirefeeder is synchronised with the power source.
It is supplied with power and controlled by the power source in the welding system.
The unreeling wirefeeder is available in two versions:
-
-

Application area

All indoor and automated MIG/MAG applications.

Proper use

The device is designed exclusively for wirefeeding in automated MIG/MAG welding appli-
cations in conjunction with Fronius system components. Any use above and beyond this
purpose is deemed improper. The manufacturer shall not be held liable for any damage
arising from such usage.
Utilisation in accordance with the intended purpose also comprises:
-
-
-
28
WARNING! Incorrect operation or shoddy workmanship can cause serious injury
and damage. The following documents must be completely read and understood
before commissioning the unreeling wire-feed unit:
- these operating instructions
- the operating instructions of the power source in use
- the operating instructions of all other system components
- especially the safety rules and safety instructions in the above mentioned
documents
CAUTION! Risk of injury from rotating drive parts if covers are open.
When performing maintenance or set-up work, make sure that the drive compo-
nents of the unreeling wire-feed unit cannot be started by the power source, by a
wire-feed unit or by any other system add-ons.
WF 25i REEL R /4R
Integrated version with 4-roller drive
WF 30i REEL R /2R
Integrated version with 2-roller drive - not permitted in conjunction with a basket-type
spool
carefully reading these operating instructions
following all the instructions and safety rules in these operating instructions
performing all stipulated inspection and maintenance work
