CrashBox /i

CrashBox /i
Item numbers
Reset accuracy (1)
Triggering torques in x/y direction
Maximum deflection in x/y direction
Weight
Dimensions
a)
At a distance of 300 mm from the robot flange
b)
With bellows: Ø110 mm
CrashBox /i
CrashBox /i XL
CrashBox /i XXL
CrashBox Drive /i PAP
CrashBox Drive /i PAP XXL
CrashBox /i
CrashBox /i XL
CrashBox /i XXL
CrashBox Drive /i PAP
CrashBox Drive /i PAP XXL
CrashBox /i
CrashBox /i XL
CrashBox /i XXL
CrashBox Drive /i
CrashBox Drive /i PAP XXL
CrashBox /i
CrashBox /i XL
CrashBox /i XXL
CrashBox Drive /i PAP
CrashBox Drive /i PAP XXL
44,0350,3589
44,0350,3760
44,0350,3380
44,0350,3379
44,0350,3754
a)
± 0.05 mm
See table on the
following page
~ 45°
~ 45°
~ 45°
~ 30°
~ 30°
1200 g
1200 g
1200 g
920 g
920 g
b)
Ø90 mm x 60 mm
b)
Ø90 mm x 60 mm
b)
Ø90 mm x 60 mm
b)
Ø90 mm x 84.5 mm
b)
Ø90 mm x 84.5 mm
