Robot welding torch

Safety

General

The following torch bodies are recommended for the CMT process:
-
-
The following maximum angles are permitted during the CMT process:
-
-
The robot welding torch transmits the arc power to the workpiece. The gas or water-cooled
TPS/i welding torch is designed for use with the CrashBox /i.
The torch body has an integrated lead for gas nozzle touch sensing.
Standard:
OVT/WWP:
TXi:
TXM:
CAUTION! Risk of burns from hot torch neck, hot torch neck coupling and other
hot welding torch components. Before starting work on the torch neck, the torch
neck coupling and all other welding torch components:
- allow the torch neck, torch neck coupling and all other welding torch compo-
nents to cool down to room temperature (+25 °C, +77 °F)
- wear electrically insulated and heat protective gloves
- use a suitable tool
MTB 250i / 320i / 400i / 500i / 700i: 22 - 36°
MTB 330i: 22°
MTB 250i / 320i / 400i / 500i / 700i: 45°
MTB 330i: 36°
with wearing parts, without contact tip
without wearing parts
automatic torch body changeover
manual torch body changeover
