Overview of the
TPS /i PAP CMT
welding system
max. 6 m
(3)
(2)
(15)
0 - max. 8 m
A
(13)
(1)
(12)
(1)
(2)
(3)
(4)
(5)
(6)
(7)
(8)
(9)
(10)
(11)
(12)
(13)
(14)
(15)
(4)
(14)
Wire drum
Unreeling wirefeeder, for example WF 30i REEL 2R
Wirefeeding hose
Interconnecting hosepack
Media splitter, for example SB 500i R
"QuickConnect" option
Torch hosepack
CrashBox and robot flange
WF 60i Robacta Drive CMT
Robot welding torch
Wire buffer
Service station, for example Robacta TX/i
Trolley or upright console
Cooling unit, for example CU 1400i Pro
Power source, for example TPS 320i
SpeedNet Cable CON
(3) (5) (4) (6)
max.
4 m
(7)
(8)
(9)
(10)
(11)
25
