Control elements, connections and mechanical
components of the SplitBox

Safety

Control elements,
connections and
mechanical com-
ponents
Front of SB 500i R (right variant)
(3)
Front of SB 500i R (left variant)
No.
(1)
(2)
(3)
WARNING! Operating the equipment incorrectly can cause serious injury and
damage. All the functions described may only be used by trained and qualified
personnel. Do not use the functions described until you have thoroughly read and
understood the following documents:
- this document
- all the operating instructions for the system components, especially the safe-
ty rules
(1) (6)
(9) (4)
Function
Blanking cover for option 3
Blanking cover for option 4
Blanking cover for option 1
Rear of SB 500i R (right variant)
(8) (7)
(10) (2)
Rear of SB 500i R (left variant)
(5)
45
