Robot welding torch

X / I (10 min/40°C)
max
M21 (EN 439)
X / I (10 min/40°C)
max
C1 (EN 439)
[mm (in.)]
Ø
* D.C. = Duty cycle
X / I (10 min/40°C)
max
M21 (EN 439)
X / I (10 min/40°C)
max
C1 (EN 439)
[mm (in.)]
Ø
* D.C. = Duty cycle
X / I (10 min/40 °C)
max
M21 (EN 439)
X / I (10 min/40 °C)
max
C1 (EN 439)
[mm (in.)]
Ø
* D.C. = Duty cycle
X / I (10 min/40 °C)
max
M21 (EN 439)
X / I (10 min/40 °C)
max
C1 (EN 439)
[mm (in.)]
Ø
* D.C. = Duty cycle
144
MTB 250i G/R
(TX, TXM)
40% D.C.* 250
60% D.C.* 200
100% D.C.* 170
-
60% D.C.* 250
100% D.C.* 200
0.8–1.2 (.030–.045)
MTB 350i G/R
(TX, TXM)
40% D.C.* 350
60% D.C.* 300
100% D.C.* 250
-
60% D.C.* 350
100% D.C.* 300
0.8–1.6 (.030–.062)
MTB 250i W/R (TX, TXM) MTB 330i W/R (TX, TXM) MTB 400i W/R (TX, TXM)
-
-
100% D.C.* 250
-
-
100% D.C.* 250
0.8-1.2 (0.032-0.047)
MTB 500i W/R (TX, TXM)
-
-
100% D.C.* 500
-
-
100% D.C.* 500
1.0-1.6 (0.039-0.063)
MTB 320i G/R
(TX, TXM)
40% D.C.* 320
60% D.C.* 260
100% D.C.* 210
-
60% D.C.* 320
100% D.C.* 260
0.8–1.6 (.030–.062)
MTB 400i G/R
(TX, TXM)
40% D.C.* 400
60% D.C.* 320
100% D.C.* 260
-
60% D.C.* 400
100% D.C.* 320
0.8–1.6 (.030–.062)
-
-
100% D.C.* 330
-
-
100% D.C.* 330
0.8-1.6 (0.032-0.063)
MTB 700i W/R (TX, TXM)
-
-
100% D.C.* 700
-
-
100% D.C.* 700
1.0-1.6 (0.039-0.063)
MTB 330i G/R
(TX, TXM)
40% D.C.* 330
60% D.C.* 270
100% D.C.* 220
-
60% D.C.* 330
100% D.C.* 270
0.8–1.6 (.030–.062)
-
-
100% D.C.* 400
-
-
100% D.C.* 400
0.8-1.6 (0.032-0.063)
