Coastcom D/I Mux III System User Manual page 89

Card Slot
R & T
1 P4 - 1/26
2 P4 - 2/27
3 P4 - 3/28
4 P4 - 4/29
5 P4 - 5/30
6 P4 - 6/31
7 P4 - 7/32
8 P4 - 8/33
9 P4 - 9/34
10 P4 - 10/35
11 P4 - 11/36
12 P4 - 12/37
13 P1 - 1/26
14 P1 - 2/27
15 P1 - 3/28
16 P1 - 4/29
17 P1 - 5/30
18 P1 - 6/31
19 P1 - 7/32
20 P1 - 8/33
21 P1 - 9/34
22 P1 - 10/35
23 P1 - 11/36
24 P1 - 12/37
Chapter 3. Installation
Table 3-10. 50-Pin Connector Pin-Outs
for the 24-Slot Shelf
Channel A
R1 & T1
P5 - 1/26 P6 - 1/26
P5 - 2/27 P6 - 2/27
P5 - 3/28 P6 - 3/28
P5 - 4/29 P6 - 4/29
P5 - 5/30 P6 - 5/30
P5 - 6/31 P6 - 6/31
P5 - 7/32 P6 - 7/32
P5 - 8/33 P6 - 8/33
P5 - 9/34 P6 - 9/34
P5 - 10/35 P6 - 10/35
P5 - 11/36 P6 - 11/36
P5 - 12/37 P6 - 12/37
P2 - 1/26 P3 - 1/26
P2 - 2/27 P3 - 2/27
P2 - 3/28 P3 - 3/28
P2 - 4/29 P3 - 4/29
P2 - 5/30 P3 - 5/30
P2 - 6/31 P3 - 6/31
P2 - 7/32 P3 - 7/32
P2 - 8/33 P3 - 8/33
P2 - 9/34 P3 - 9/34
P2 - 10/35 P3 - 10/35
P2 - 11/36 P3 - 11/36
P2 - 12/37 P3 - 12/37
M & E R & T
P4 - 13/38
P4 - 14/39
P4 - 15/40
P4 - 16/41
P4 - 17/42
P4 - 18/43
P4 - 19/44
P4 - 20/45
P4 - 21/46
P4 - 22/47
P4 - 23/48
P4 - 24/49
P1 - 13/38
P1 - 14/39
P1 - 15/40
P1 - 16/41
P1 - 17/42
P1 - 18/43
P1 - 19/44
P1 - 20/45
P1 - 21/46
P1 - 22/47
P1 - 23/48
P1 - 24/49
69
Channel B
R1 & T1 M & E
P5 - 13/38 P6 - 13/38
P5 - 14/39 P6 - 14/39
P5 - 15/40 P6 - 15/40
P5 - 16/41 P6 - 16/41
P5 - 17/42 P6 - 17/42
P5 - 18/43 P6 - 18/43
P5 - 19/44 P6 - 19/44
P5 - 20/45 P6 - 20/45
P5 - 21/46 P6 - 21/46
P5 - 22/47 P6 - 22/47
P5 - 23/48 P6 - 23/48
P5 - 24/49 P6 - 24/49
P2 - 13/38 P3 - 13/38
P2 - 14/39 P3 - 14/39
P2 - 15/40 P3 - 15/40
P2 - 16/41 P3 - 16/41
P2 - 17/42 P3 - 17/42
P2 - 18/43 P3 - 18/43
P2 - 19/44 P3 - 19/44
P2 - 20/45 P3 - 20/45
P2 - 21/46 P3 - 21/46
P2 - 22/47 P3 - 22/47
P2 - 23/48 P3 - 23/48
P2 - 24/49 P3 - 24/49
