The Display Modem and Port Expander Configuration screen appears, listing all current alarm dial-out
configuration data. Figure J-8 depicts a modem and port expander configuration screen.
16:49:16 -------------[ Alarm Dial Out ]------------- 07/09/92
Interval Between Calls : 3 mins
Port Expander Present
NCC Port
Port
Attention String
Link String
Link Response
Unlink String
Unlink Response
Modem Present
Phone Number
Attention String
Init. String
** Press Enter to Continue **
Current Mode
TERM - NO ALARM REPORTING
Figure I--8. Display Modem and Port Expander Configuration Screen

Feature Group 6.0/6.2 Screen Changes

The 6.0/6.2 Feature Group Current Mode status was not labeled. It simply indicated alarm
reporting, but did not specify reporting to the terminal.
Last Message Time Out : 20 secs
: No
: 0
: 1
: 1t.r.o.P
: L
: LINK ESTABLISHED
: U
: UNLINK DONE
: No
:
: ~~~+++~~~ATH!
: ATE0S0=1Q1V1X4&C0&D0!
