D/I Mux III User's Manual
ma
]
Modify T1 Alarm Trap Conditions
-------------------------------
1 Modify T1 line one criteria
Q Quit
1
Select: [Q]
15:43:37 --------[ Set T1 Line Trap Criteria - T1 One ]-------- 06/19/97
If any alarm marked Check is present, the T1 line will be considered down. Unmarked alarms are ignored.
------------------------------------------------------------------------
0: Receive Far End LOF (Yellow) ..... [
1: Transmit Far End LOF (Yellow) .... [
2: Receive AIS (Blue) ............... [
3: Transmit AIS (Blue) .............. [
4: Near End Loss Of Frame (Red) ..... [
5: Near End Loss Of Signal .......... [
6: Loopback ......................... [
7: Bypass ........................... [
8: Carrier Group Alarm .............. [
9: Delayed Carrier Group Alarm ...... [
A: Any Alarm
N: None
Q: Quit
Chose a number to change the state of that alarm, or chose a letter for
the specified action: [Q]
]
]
]
]
]
]
]
]
]
]
8
.
Figure J-2 Modify alarm Screen
Appendix I. Traps and Modem Dial Out Configuration
