D/I Mux III Messages

Table 5-4 lists all of the D/I Mux III error and status messages. Messages appear within the table in
alphabetical order.
Error Message
Card Removed Card not in slot.
Clock Sources Fixed The clock source cannot be
In ALPS Loop Mode changed when in ALPS loop mode
with loop shelf timing; it can only be
changed with local shelf timing.
Clock Sources Fixed The clock source cannot be
In Channel changed when in channel bank
Bank/Loop Mode mode with loop shelf timing; it can
only be changed with local shelf
timing.
Command Not No acknowledgment of the
Processed command being processed by the
system
First Unbypass Shelf The loopback command entered
cannot be performed until the shelf
is out of bypass mode.
Invalid Command This level password excludes use of
for Password the entered command.
Invalid DS0 Range Either the DS0 range was outside
(1-24) the range of 1 to 24, or the first
number of the range was greater
than the second number.
Invalid Entry The entry is not a valid value for this
command, e.g., a letter was entered
instead of a number, a number was
entered instead of a letter, etc.
Invalid Map Number The map number entered was not a
(1..7) number between 1 and 7.
Invalid Password The password entered while logging
in was incorrect.
Invalid Slot Number The slot number entered was not a
(1..N) number between 1 and 8 for the 8-
slot shelf; or not a number between
1 and 12 for the 12-slot shelf; or not
a number between 1 and 24 for the
24-slot shelf.
Chapter 5. Diagnostics
Table 5-4. D/I Mux III Messages (Page 1 of 3)
Cause Solution
Replace card.
Informational message only; no action
required.
Informational message only; no action
required.
Check that the command requested
matches the installed equipment.
Take the shelf out of bypass mode, then
enter the loopback command again.
Log out, then enter the correct-level
password that allows use of the entered
command. See Chapter 4. Configuration and
Operation, for a description of password
levels, and the commands allowed at each
level.
Check the range, then enter the numbers
again.
Enter a valid value for this command.
Enter a map number between 1 and 7.
Verify that the password is correct, then
enter the password again.
Check the slot number, then enter the
number again. Check for proper shelf size
selection, using SP command.
