MG - Modifying/Setting the Gateway Address

From the AMCU Main Menu, use the MG command to Modify/set the Gateway address. The screen
depicted in Figure 4-16 will appear. The Gateway Address must be on the same network, both by IP
Address class and by Subnet Mask, as the current AMCU IP Address.
] MG
Changing the Gateway Address requires rebooting the unit.
Do you want to continue [N] y
Do you want to define a gateway? [N] y
Enter the Gateway IP Address [None]: 130.1.10.50
Stand by to reboot.
Password:
Welcome to Coastcom D/I Mux III Configuration System
Copyright (c) 1995 - Coastcom, Alameda, California
15:15:37 06/08/95
Access Level is: 1
Type ? for Help
]VN
15:15:42 ----------[ Network Parameters ]--------- 06/08/95
MAC Address:
IP Address:
Subnet Mask:
Default Gateway:
SLIP Parameters:
Local IP Address:
Peer IP Address:
MTU:
Data Rate:
-----------------------------------------------------------
]
Chapter 4. Configuration and Operation
Confirm? [N] y
00:A0:70:00:00:02
130.1.10.99
255.255.255.0
130.1.10.50
130.1.10.98
130.1.10.97
1006
9600
Figure 4-26. Modifying the Gateway Address
125
