If single channel bank or dual channel bank is selected, the system queries as to whether timing should
be loop or local shelf timing (Figure 4-48).
Shelf Timing
L) Loop
C) Local
[ ]
When Loop timing is selected for dual channel bank mode, the system prompts with the following
choices as shown in Figure 4-49.
Network Clock Connected to
1) T1-1
2) T1-2
3) T1-1 and T1-2
[ ]
Figure 4-49. Selecting Network Clock with Loop Timing for Dual Channel Bank Operation
For all modes except ALPS, the system displays the screens below (Figures
4-50 and 4-51), in order to specify a frame mode, and zero suppression mode, compatible with the
network.
Frame Mode
S) D4/SF
E) ESF
[ ]
Chapter 4. Configuration and Operation
Figure 4-48. Selecting Shelf Timing
Figure 4-50. Specifying Frame Mode
