D/I Mux III User's Manual Appendix F. MIB II and DS1 MIB Group Names and Objects
Table F-1. MIB-II Groups and Objects (Continued)
Group/Object Name Description
ipReasmTimeout The maximum number of seconds which
received fragments are held while they are
awaiting reassembly at this entity.
The number of IP fragments received that
ipReasmReqds
required reassembly at this entity.
ipReasmOKs The number of IP datagrams successfully
reassembled.
ipReasmFails The number of failures detected by the IP
reassembly algorithm (for any reason: timed
out, errors, etc.).
ipFragOKs The number of IP datagrams successfully
fragmented at this entity.
The number of IP datagrams discarded
ipFragFails
because they needed to be fragmented at this
entity, but could not be (e.g., because their
Don't Fragment flag was set).
ipFragCreates The number of IP datagram fragments
generated as a result of fragmentation at this
entity.
The table of addressing information relevant to
ipAddrTable
this entity's IP addresses.
The addressing information for one of this
ipAddrEntry
entity's IP addresses.
ipAdEntAddr The IP address to which this entry's addressing
information pertains.
ipAdEntIfIndex The index value which uniquely identifies the
interface to which this entry is applicable.
ipAdEntNetMask The subnet mask associated with the IP
address of this entry.
The value of the least-significant bit in the IP
ipAdEntBcastAddr
broadcast address used for sending datagrams
on the (logical) interface associated with the
IPaddress of this entry.
ipAdEntReasmMaxSize The size of the largest IP datagram which this
entity can reassemble from incoming IP
fragmented datagrams received on this
interface.
This entity's IP Routing table.
ipRouteTable
The destination IP address of this route.
ipRouteDest
