Coastcom D/I Mux III System User Manual page 312

D/I Mux III User's Manual Appendix I. Traps and Modem Dial Out Configuration
MODIFY DIAL OUT
After inputting the "MD" command, the first menu selection lets the user tell the system whether or not to
configure the SLIP port for a modem
md
]
Modify Dial Out Parameters
-------------------------------
M Modem present?
T Timeout
I Modem initialization string
N Dail out numbers
V View dial out parameters
Q Quit
m
Select parameter to set or modify [Q]
Figure J-5 Select Modify Dial Out
MODEM PRESENT?
After choosing the M option the user now selects Y for "yes configure the SLIP port for a modem. N says
"no don't configure this SLIP port for a modem.
Yes
Modem Connected to SLIP port:
Y Configure for modem
N configure for no modem
Q Quit
[Q]
Figure J-6 Connect Modem to SLIP Port
292
