DD - Displaying Line Card Data Configuration

Enter DD to Display the line card Data configuration screen (Figure 4-12). In the example below, the
system displays the last card slot operated (which in the example is card slot 5). The current card under
observation is in card slot 3, and it is an intelligent Dual 4-Wire channel card.
] DD
Slot Number
[5] 3
10:15:59---------------- [ Slot 3 : D4W ] ---------------03/08/95
Current Channel Status
Ch. A: CGA
Ch. B: Not Mapped
Direction
Signalling Type
Signalling Mode
Chan. Label
----- -----
A
B
---Hardware---
Card Type Part Number
---------------------------------------------------------------
D4W 33245-103
---------------------------------------------------------------
Note: Screens will vary depending on the type of card configured. Refer to the appropriate line card user's manual, and its
configuration chapter, for the specific configuration screen desired.
Chapter 4. Configuration and Operation
: T1-1
: E&M Type 1&3
: Normal E&M
Tx Level Rx Level
-------- ----------
-16.0 dBm +7.0 dBm
-16.0 dBm +7.0 dBm
Serial
Rev Number
L 210710-0059
Figure 4-12. Displaying Line Card Data Screen
Loopback : Not Active
CGA : Type-3
Software
Revision
E 06/18/92
