D/I Mux III User's Manual
Group/Object
dsx1ConfigTable
dsx1ConfigEntry
dsx1LineIndex
dsx1IfIndex
dsx1TimeElapsed
dsx1ValidIntervals
dsx1LineType
dsx1LineCoding
dsx1SendCode
dsx1CircuitIdentifier
dsx1LoopbackConfig
dsx1LineStatus
dsx1SignalMode
dsx1TransmitClockSource
dsx1Fdl
dsx1CurrentTable
dsx1CurrentEntry
Table F-2. DS1 MIB (RFC 1406) Groups and Objects
DS1 Near End Group
Appendix F. MIB II and DS1 MIB Group Names and Objects
Description
The DS1 Configuration table.
An entry in the DS1 Configuration table.
This object is the identifier of a DS1 Interface on a
managed device.
This object's value is equal to the value of ifIndex
from the MIB II Interface table (RFC 1213).
The number of seconds that have elapsed since the
beginning of the current error-measurement period.
The number of previous intervals for which valid data
was collected.
This variable indicates the variety of DS1 Line
implementing this circuit.
This variable describes the variety of Zero Code
Suppression used on the link, which in turn affects a
number of its characteristics.
This variable indicates what type of code is being
sent across the DS1 interface by the device.
This variable contains the transmission vendor's
circuit identifier, to facilitate troubleshooting.
This variable represents the DS1 interface loopback
configuration.
This variable indicates the interface Line Status.
'None' indicates that no bits are reserved for
signaling on this channel.
'RobbedBit' indicates that T1 Robbed Bit Signaling is
in use.
'Bit-Oriented' indicates that E1 Channel Associated
Signaling is in use.
'MessageOriented' indicates that Common Channel
Signaling is in use either on channel 16 of an E1 link
or channel 24 of a T1.
The source of Transmit Clock.
This is the facilities data link, and is the sum of the
capabilities. 'Other' indicates that a protocol other
than one following is used.
The DS1 Current table.
An entry in the DS1 Current table.
