Performance

Enter PM to begin the Performance Monitoring sequence. This screen will only appear if a Facilities
Data Link Processor (FDLP) is installed in the multiplexer. Consult the FDLP User's Manual for the
various options of the Performance Monitor screen, as depicted in Figure 5-28.
] PM
10:40:23---------- [ PERFORMANCE MONITOR ]----------- 03/08/96
Select Direction
A) T1-1
B) T1-2
C) Both
[ T1-1 ]
Screen Reports
0) Current Status
1) 1 Hour
2) 24 Hour
3) ANSI
Logging of Network Messages
L) Disable
M) Enable With Data
N) Enable Without Data
[ T1-1 Disabled & T1-2 Disabled ]
S) Serial Port Setup
Q) Quit
Chapter 5. Diagnostics
Select Side
D) User
E) Network
F) Both
[ User ] [ AT&T/ANSI T1-1 & None T1-2 ]
Clear Counters
4) ESF Errors
5) Others
Network May Reset User Counters
P) Disable
R) Enable
[ T1-1 Enabled & T1-2 Enabled ]
Figure 5-28. Performance Monitor Screen
AT&T/ANSI
G) AT&T
H) ANSI
I) Both
Printer Reports
6) ESF Error Counts
7) 1 Hour
8) 24 Hour
9) ANSI
