] CL
Copy Line Card Configuration
Source Slot Number
[1..12] 1
Destination:
Slot Range
*) All Slots
[1..12] 2
Are You Sure?
Y) Yes
N) No
[Y/N]
In the example shown in Figure 4-8, the source slot number is the card configuration to be copied from
(slot 1), and the destination slot number (slot 2) receives the copied line card configuration.
DO NOT copy a single card configuration to more than 12 line cards at once or all line cards will be configured to
the same T1 channel. When configuring a 24-slot multiplexer, copy the configuration in two phases. Ensure that
only cards assigned to T1-1 are copied to other cards being used on T1-1. This applies to T1-2 cards also. DO
NOT mix T1-1 and T1-2 cards during the copy process.
Switching to another map, then returning to the working map, usually forces cards to resume normal
communications.
Chapter 4. Configuration and Operation
Figure 4-8. Copying Line Card Configuration
WARNING!
110
