Coastcom D/I Mux III System User Manual page 254

D/I Mux III User's Manual
Group/Object Name
tcpEstabResets
tcpCurrEstab
tcpInSegs
tcpOutSegs
tcpRetransSegs
tcpConnTable
tcpConnEntry
tcpConnState
tcpConnLocalAddress
tcpConnLocalPort
tcpConnRemAddress
tcpConnRemPort
tcpInErrs
tcpOutRsts
udpInDatagrams
udpNoPorts
udpInErrors
Table F-1. MIB-II Groups and Objects (Continued)
UDP Group
Appendix F. MIB II and DS1 MIB Group Names and Objects
Description
The number of times TCP connections have
made a direct transition to the CLOSED state
from either the ESTABLISHED or the CLOSE-
WAIT state.
The number of TCP connections for which the
current state is either ESTABLISHED or CLOSE-
WAIT.
The total number of segments received,
including those received in error.
The total number of segments sent, including
those on current connections but excluding those
containing only retransmitted octets.
The total number of segments retransmitted,
(i.e., the number of TCP segments transmitted
that contain one or more previously transmitted
octets).
A table containing TCP connection-specific
information.
Information about a particular current TCP
connection.
The only value which may be set by a
management station is deleteTCB (12).
The local IP address for this TCP connection.
The local port number for this TCP connection.
The remote IP address for this TCP connection.
The remote port number for this TCP connection.
The total number of segments received in error
(e.g., bad TCP checksums).
Number of TCP segments sent containing RST
flag
The total number of UDP datagrams delivered to
UDP users.
The total number of received UDP datagrams for
which there was no application at the destination
port.
The number of received UDP datagrams that
could not be delivered for reasons other than the
lack of an application at the destination port.
234
