Page 1 D/I Mux III System For D/I Mux III Shelf and Common Equipment USER’S MANUAL 30000-100-MOD Issue C November 2005...
Page 2 PUBLICATION RELEASE RECORD Publication Number: 30000-100-MOD Publication Name: D/I Mux III System User’s Manual DATE ISSUE ECO NO. REASON FOR CHANGE Aug 1997 Combine CCU and AMCU. Add new standard LIUs. Add FLIU. Revise to Feature Group upgrade. February 302-267 Delete FLIU Appendix.
Page 3 RELEASE NOTE August 2005 UPGRADED POWER SUPPLY UNITS FOR D/I Mux III In August 2005, Coastcom released upgraded power supply units for the D/I Mux III. The following two new units replace part numbers 30338-102, 30315-105A, 30338-103A, and 30308- 102A.
Page 4 D/I MUX III User’s Manual RELEASE NOTE August 2005 RING GENERATOR MODULE FOR D/I Mux III Introduction: The 30333-101 / 121 Ring Generator provides internally generated ringing voltage for AC or DC powered D/I Mux III shelves with 2W FXS and Smart Omni-Orderwire feature cards. The 30333-101 is a –48 volt powered unit while the 30333-121 is a –24 volt powered unit.
Page 5 AC/DC power supply has to power all –48 Volt requirements in the shelf (CSU and talk battery for FXS and Smart Omni Orderwire, etc.) along with powering the Ring Generator. If in doubt regarding an application with high internal AC powered loading, contact Coastcom application engineering (800-433-3433).
Page 6 Voice, data, video, and special services are provided in any combination within a D/I Mux III. With the addition of Coastcom's 5-port Subrate Data Multiplexer (SDM) line cards, up to 120 data circuits are supported in a single multiplexer.
Page 7: Design Compliance
1997 by Coastcom. All Rights Reserved. Printed in the United States of America. No Coastcom document, or parts thereof, may be reproduced in any form without prior written permission from Coastcom except where otherwise noted. The information in this manual is subject to change without notice. D/I Mux III, ALPS, and ®...
Page 8 • Appendices Coastcom recommends a thorough review of the content and organization of this manual. An extensive table of contents provides easy access to installation and maintenance information. At each step of the installation process, applicable procedures should be re-read carefully to ensure that the required tools...
Page 9: Federal Communications Commission (Fcc)
Note: FCC Rules Part 68 require the following information to be included in this publication. Some of the information may not be relevant to Coastcom equipment. FCC regulations and telephone company procedures prohibit connection of customer-provided equipment to telephone company provided coin service central office implemented systems. Connection to party line service is subject to state tariffs.
Page 10 D/I MUX III User’s Manual The REN is used to determine the quantity of devices that may be connect to the telephone line and still have assurance that all of those devices will ring properly when the applicable number is called. In most, but not all areas, the sum of the RENs of all devices should not exceed five (5).
Page 11 Advance notice of changes should be given by the telephone company to provide an opportunity to maintain uninterrupted service. Repair Services In the event equipment repairs are necessary, contact Coastcom for factory service. Customer repairs of Coastcom equipment should be limited to module replacement and/or front panel servicing. For information, contact:...
Page 12: Safety Agency Certifications
D/I MUX III User’s Manual SAFETY AGENCY CERTIFICATIONS Canadian Standards Association (CSA) certifies that D/I Mux III equipment meets the requirements of Underwriter’s Laboratories (UL), as applicable, for the United States, and those of CSA, as applicable, for Canada. When a DC powered system is purchased to be resold to another customer, or when purchased to be used as part of another system, the system is referred to as a Rack Mounted Card Cage and is CSA Certified.
Page 13: Table Of Contents
D/I MUX III User’s Manual TABLE OF CONTENTS RELEASE NOTE UPGRADED POWER SUPPLY UNITS FOR D/I MUX III............. I RELEASE NOTE RING GENERATOR MODULE FOR D/I MUX III ................. II Design Compliance ............................ v Federal Communications Commission (FCC) .................... vii Part 15 Regulations For Telephone Equipment..................
Page 14 D/I MUX III User’s Manual Shelf Backplane Connectors ......................18 Common Equipment Units and Line Cards ....................19 Common Equipment........................... 19 Common Control Unit........................19 CCU Circuit Description ....................... 21 Advanced Multiplexer Control Unit (AMCU) ................. 22 AMCU Motherboard Circuit Description ..................22 AMCU Sub-Board Circuit Description...................
Page 15 Transmission Connection ........................... 99 Cable ................................99 Line Card Installation..........................100 System Power-Up and Initialization ......................100 Configuring the D/I Mux III System ......................100 CHAPTER 4. CONFIGURATION AND OPERATION....................101 Setup and Programming Order ........................103 Screen Display and Data Entry........................104 Obtaining System Access...........................
Page 16 D/I MUX III User’s Manual DD - Displaying Line Card Data Configuration ................... 114 DH - Displaying Alarm History ........................115 DM - Displaying Map Matrix........................117 DN - Displaying the Current Working Map....................119 DP - Displaying System Parameters ......................119 DS - Displaying Clock Source........................
Page 17 D/I MUX III User’s Manual B7 Alarm ............................163 BPV Alarm ........................... 163 0-DEN Alarm ..........................163 Loop Codes Alarms........................163 Alarm Contacts............................163 Alarm Dialout.............................. 164 ACO Button ..........................164 Bypass Button ..........................164 Bypass................................ 164 Power-Up Sequence ..........................165 Troubleshooting............................
Page 18 APPENDIX F. MIB II AND DS1 MIB GROUP NAMES AND OBJECTS ..............226 APPENDIX G. MODEM INTERFACES ........................246 General Modem Operation ......................... 246 Hayes Command Set ..........................246 Special Coastcom Characters ........................246 NCC Characters........................... 246 D/I Mux III Characters ........................247 DXC II Characters ........................247 Hayes 1200 and 1200B Command Sets ....................
Page 19 D/I MUX III User’s Manual Setting Communications in Terminal Mode With Alarm Reporting Off ............ 270 Feature Group 6.0/6.2 Screen Changes ..................270 Setting Communications in MML Mode With Modem Dial-Out Enabled..........272 Feature Group 6.0/6.2 Screen Changes ..................272 Setting Communications in MML Mode With Modem Dial-Out Disabled ..........
Page 21: Chapter 1. System Overview And Modes Of Operation
Chapter 1. System Overview and Modes of Operation Chapter 1. SYSTEM OVERVIEW AND MODES OF OPERATION This manual details the Coastcom D/I Mux III multiplexer for use with T1 connections. Users unfamiliar with T1 technology are encouraged to refer to commercially published material on T1 for more information, however the basic concepts of T1 are relatively simple.
Page 22: D/I Mux Iii Functions
D/I Mux III Features A D/I Mux III system includes the following features: • A multi-tasking microprocessor for rapid reconfiguration and quick response to changing network conditions •...
Page 23: D/I Mux Iii Software Control
Figure 1-1. Software Control AIM-NET EMS Coastcom’s AIM-Net is a Windows-based enhanced Element Management System (EMS) designed to simplify the construction and mapping of complex voice and data networks. This unique software management tool was designed in support of our AIM and D/I Mux III product lines, empowering the user to set up, configure, view, and manage an entire mixed network from a single location.
Page 24: Remote Control With Ncc
Figure 1-2. AMCU System Network Remote Control with AMCU Remote control of the D/I Mux III system is made possible through the use of a modem connection to the D/I Mux III COM port (also referred to as the control port). A terminal and modem are connected at the user site, and call up the remote system using terminal emulation software.
Page 25 Network management achieves these goals, and SNMP is the most widely accepted market standard for Transmission Control Protocol-Internet Protocol (TCP/IP)-based environments. Coastcom implements SNMP using a powerful AMCU that offers the following features: • Native SNMP that eliminates the need for proxy hardware •...
Page 26: Serial Line Internet Protocol (Slip)
Chapter 1. System Overview and Modes of Operation Serial Line Internet Protocol (SLIP) A D/I Mux III with the SNMP option will usually be connected through a Local Area Network (LAN) to one or more SNMP managers. The network connection can be made either through an Ethernet 10Base-T, or serial port connection.
Page 27: Gateway
Chapter 1. System Overview and Modes of Operation Gateway The AMCU makes special provision for the case where it is connected to a network that is linked to other networks by a Gateway (special router). In this case, messages to the manager must be addressed to pass through the Gateway, and the address of the Gateway must be known to the AMCU.
Page 28: Transmission Channel Assignments
Chapter 1. System Overview and Modes of Operation D/I Mux III line card circuits transmit and receive information over user-assigned (mapped) DS0 channels as data or voice. The map assignments are user programmed and the information is recorded in a line card map.
Page 29: Timing And Clock Source
Chapter 1. System Overview and Modes of Operation Timing and Clock Source Transmit clocks for the T1-1 and T1-2 transmission ports are derived from the sources illustrated in Table 1-1 below. Table 1-1. Clock and Timing Source Clock Source Timing Source T1-1/T1-2 Recovered Loop Internal T1...
Page 30: Power Failure Alarm
Chapter 1. System Overview and Modes of Operation There are many other alarms in the D/I Mux III system. Alarms are rated as major, minor, and informational. Details of the various alarms are described in Chapter 5. Diagnostics. Power Failure Alarm All of the alarm contacts on the D/I Mux III are open during non-alarm conditions.
Page 31: Trunk Processing
Chapter 1. System Overview and Modes of Operation Trunk Processing When a local alarm, remote alarm, or system failure causes a Carrier Group Alarm (CGA) to occur, trunk processing removes line cards from service in the D/I Mux III. When the problem is cleared, service is restored.
Page 32: Power Supplies
An AC power supply is available for customer premise applications where only standard 110 V AC power is available. Coastcom currently offers an AC/DC self-contained single-slot power supply that provides all of the voltages necessary to operate a D/I Mux III - except ringing voltage.
Page 33: D/I Mux Iii User Circuit Interfaces
Chapter 1. System Overview and Modes of Operation D/I Mux III User Circuit Interfaces D/I Mux III circuit interfaces include: • High speed synchronous data • 56 Kbps to 1.536 Mbps (n times 56 or 64 Kbps) • V.35 interface, RS-422/449, or RS-232C interface •...
Page 34: Circuit Features
Chapter 1. System Overview and Modes of Operation • 4-Wire Voice • E&M (Types I, II, III, & V) • Pulse Link Repeater (PLR) • Transmission Only (TO) • Modem • Deluxe card with 2713 Hz loopback tone • • High fidelity audio •...
Page 35: Component Overview
Chapter 1. System Overview and Modes of Operation COMPONENT OVERVIEW The Coastcom D/I Mux III multiplexer incorporates a modular design that is cost effective in meeting specific applications, and requiring purchase of only what is needed. Modular system components are easily added or removed as network requirements change, also simplifying maintenance.
Page 36 Chapter 1. System Overview and Modes of Operation...
Page 37: Shelves
Shelves house the common equipment and channel units. The shelf backplane supplies the bus connectivity for provisioning the common equipment and channel units. Coastcom D/I Mux III multiplexers include the following shelf types (see Figure 1-8). • D/I Mux III, 8-slot with 8 line card slots and 2 T1 transmission ports •...
Page 38: Shelf Backplane Connectors
Chapter 1. System Overview and Modes of Operation Figure 1-8. D/I Mux III 8-, 12- and 24-Slot Shelves Shelf Backplane Connectors A DB-9 female connector can be used as a synchronous input/output (Sync I/O) port to synchronize the D/I Mux III with other systems. Both the synchronous output and the external clock input are available on the DB-9 simultaneously.
Page 39: Common Equipment Units And Line Cards
Status Figure 1-9. Typical D/I Mux III Channel Card Common Equipment The following section lists and describes the D/I Mux III system common equipment. The common equipment functions are illustrated in simplified block diagrams. Common Control Unit The Common Control Unit (CCU) stores the operating parameters for control and monitoring of all common equipment and channel cards in the D/I Mux III.
Page 40 Chapter 1. System Overview and Modes of Operation Figure 1-10. Common Control Unit Block Diagram...
Page 41: Ccu Circuit Description
Chapter 1. System Overview and Modes of Operation CCU Circuit Description The following section lists and describes the various components comprising the Common Control Unit (CCU). Microcontroller The microcontroller, running a real time multi-tasking operating system, controls all the functions of the CCU, provides alarm integration, accepts user commands over either the asynchronous terminal or network interface, and issues commands to other provisionable units over the RS-485 provisioning bus.
Page 42: Advanced Multiplexer Control Unit (Amcu)
The Advanced Multiplexer Control Unit (AMCU) is a two-circuit board assembly, comprising the control functions of the D/I Mux III system with the SNMP feature. It is incompatible with all releases of NCC products, and does not support Coastcom proprietary Machine Machine Language (MML).
Page 43 Chapter 1. System Overview and Modes of Operation RS-485 Provisioning Bus Interface Communication between the common equipment and line cards takes place over a balanced serial bus at a data rate of 19.2 Kbps. This polled multidrop system allows only one unit to transmit over the bus at any given time.
Page 44 Chapter 1. System Overview and Modes of Operation Clock Select The clock select function provides T1 clock selection options for T1-1 and T1-2 as follows: • Recovered clock T1-1 Clock should only be present on • Recovered clock T1-2 either/or, not both , unless sourced form the same reference.
Page 45 Chapter 1. System Overview and Modes of Operation Figure 1-11. AMCU Motherboard Circuit Flow Block Diagram...
Page 46: Amcu Sub-Board Circuit Description
Chapter 1. System Overview and Modes of Operation AMCU Sub-Board Circuit Description The AMCU sub-board interfaces to the AMCU motherboard via a 20-pin connector, and includes the hardware that supports SNMP. A full TCP/IP communication protocol stack allows SNMP and Telnet to communicate with a centrally located Network Operations Center (NOC). A network manager uses automated tools (for example, to read or compile a Management Information Base, or MIB) to manage distributed node devices, including D/I Mux III multiplexers.
Page 47 Chapter 1. System Overview and Modes of Operation Microprocessor The 32-bit Reduced Instruction Set Computer (RISC) microprocessor controls all functions on the AMCU sub-board. The microprocessor executes the protocol stack, and handles communication with the Ethernet 10Base-T and serial interfaces. Flash EPROM The FLASH EPROM is 1 M x 16.
Page 48 Chapter 1. System Overview and Modes of Operation Code download occurs by external indication when a PCMCIA card is inserted, and an NVRAM power-up is initiated by pressing the ACO and BYP buttons for one minute, at system power-up. During the power-up, the AMCU will compare its software revision with that on the PCMCIA card and, if different, it will download the code to the AMCU.
Page 49 Chapter 1. System Overview and Modes of Operation AMCU User Interfaces The AMCU may be accessed in three ways: © - • An SNMP manager, such as Hewlett Packard’s OpenView An SNMP manager accesses all Management Information Base II (MIB-II) parameters supported by the SNMP agent, and all the DS1 MIB values supported by the current D/I Mux III software.
Page 50: Strobe Units
DS0 time slots and physical card slots are independent of each other; further, installing a line card does not assign its transmission path within the D/I Mux III system. Mapping controls strobe assignments, and the transmission path must be mapped. For more information on mapping, refer to Chapter 4.
Page 51 Chapter 1. System Overview and Modes of Operation...
Page 52: Line Interface Units
Chapter 1. System Overview and Modes of Operation Line Interface Units Line Interface Units (LIUs) perform the primary multiplexing functions in the D/I Mux III system. Information from the various line cards is combined and converted to T1 format, and information from the network is distributed to the line cards, through the LIUs.
Page 53 Chapter 1. System Overview and Modes of Operation Figure 1-14. Line Interface Unit Block Diagram LIU Network Loop Switch The LIU Network Loop switch sends a standard loopback code to another D/I Mux III or Channel Service Unit (CSU) at the remote end. After a network loop is established, the information sent to the remote end will return to the local D/I Mux III as a loopback.
Page 54: T1 Interface Units
Chapter 1. System Overview and Modes of Operation T1 Interface Units Coastcom offers five interfaces to the T1 transmission lines for various types of applications. There are three versions of the Dual Channel Service Unit (CSU) Interface (with integral CSU functionality), and two versions of the Dual Digital Service Cross-Connect DSX-1 Interface (with no CSU functionality).
Page 55: Power Supplies
(AIS, an unframed all-ones T1 signal) to the network. If power fails in drop-and-insert mode, the T1 signal bypasses the shelf using only the equalization networks. Power Supplies Coastcom currently offers two (2) different power supplies for use with the D/I Mux III. -48 VDC Redundant (P/N 30338-902) The 30338-902 is a DC-to-DC converter used to power D/I Mux equipment from an external -48 VDC input supply.
Page 56: Voice Line Cards
Chapter 1. System Overview and Modes of Operation The Dual Synchronous Data Channel Unit (DSDCU) is ideal for computer- aided design (CAD), computer-aided manufacturing (CAM), and high speed batch data applications. This protocol- transparent card also finds applications in multi-site polled or packetized LAN environments, and videoconferencing.
Page 57: Modes Of Operation
Chapter 1. System Overview and Modes of Operation MODES OF OPERATION There are four modes of operation available with a D/I Mux III system. The three main modes of operation are single channel bank, drop-and-insert, and dual channel bank. These modes relate to the setup, timing, and structure of the T1 network.
Page 58: Drop-And-Insert Operation
Chapter 1. System Overview and Modes of Operation Drop-and-Insert Operation In drop-and-insert operation a D/I Mux III connects two T1 transmission lines in a unique fashion, as depicted in Figure 1-18. The D/I Mux III takes clock and DS0 channels from one T1 transmission port and passes them through the system to the other T1 transmission port.
Page 59: Loop Timing
• DB-9 Clock - The DB-9 Clock is an 8 Kbps to 1.544 Mbps TTL or V.35 external clock brought into the SYNC I/O connector on the back of the D/I Mux III system shelf. • Slot 2 Synchronization - The Slot 2 Sync is an 8 Kbps to 1.544 Mbps clock recovered from a...
Page 60: Chapter 2. Applications
Figure 2-1. In this configuration, the D/I Mux III connects T1 to the public digital switching system. Network-compatible circuits are a requirement, and include all of Coastcom's standard voice frequency interfaces and Digital Dataphone Service (DDS) data cards. Each circuit is given a telephone number or circuit identifier.
Page 61: Point-To-Point Private Network
In the Proprietary mode, the DS0B can support synchronous and asynchronous transmission. Coastcom's single-port SDM line card offers DS0A DDS type data at rates of 2.4, 4.8, and 9.6 Kbps. A single DS0A data circuit takes up all of a 64 Kbps DS0 transmission channel.
Page 62 (shared). Historically, the common connection between PBXs and local central offices has been 4-Wire Earth and Magnet (E&M) trunks. Coastcom offers 4-Wire E&M line cards for connection of PBXs within a private T1 network. Corporations that conduct a large amount of communication between their various facilities can benefit by dedicating a T1 network to internal communications.
Page 63: Drop-And-Insert
Chapter 2. Applications Drop-and-Insert Drop-and-insert operation is used to transport information to several locations along a single T1 transmission line, as depicted in Figure 2-3. Systems connected to the drop-and-insert network can be used to communicate with several locations. Running one T1 line, instead of several, is highly cost effective in that transmission line costs are minimized, and a drop-and-insert network uses less equipment than does channel bank technology.
Page 64: Dual Channel Bank
Chapter 2. Applications Drop-and-insert operation is ideal for polled data networks. A data line card at a control center sends data on one of the T1 channels to all the data line cards that occupy the same DS0 transmission channel. Only the polled Data Terminal Equipment (DTE) will communicate back to the control center.
Page 65: Chapter 3. Installation
Chapter 3. Installation Chapter 3. INSTALLATION This chapter describes the D/I Mux III system shelf and common equipment hardware installation. Installation of the shelves, wiring, common equipment, and the control terminal are given in detail. A brief description of line card installation is included. Refer to individual line card user manuals for more detailed installation instructions for each line card.
Page 66: Shelves
Because all modules are inserted into the front of the shelf, enough space must exist in front of the system to allow installation and access to the modules. Coastcom recommends allowing an unobstructed depth of 18 inches at the back of the shelf for wiring access, and an unobstructed space of 30 inches at the front of the shelf for module access.
Page 67: -48 Vdc Power Systems
-48 V DC powered system. -48 V DC Power Supply Capacity Coastcom’s -48 V DC Power Supply (P/N 30338-902), either by itself or with a second 30338-902, can power all combinations of line cards up to the maximum D/I Mux III shelf capacity of 24.
Page 68: Shelf Installation
The D/I Mux III is commonly installed in a 19-inch or, with rack adapter brackets, in a 23-inch rack, or cabinet. Accessory equipment also allows the D/I Mux III to be wall- or desktop-mounted. There are two methods for wall mounting a D/I Mux III system. A description of all the installations follows. Rack and Cabinet Installation D/I Mux III shelves mount on standard 19-inch or 23-inch mounting racks.
Page 69: Desktop
Figure 3-2. Rack Installation Desktop The D/I Mux III can be mounted on a table or desk top using the Coastcom Table Mount Base (P/N 117667-01). The Table Mount Base is recommended because it allows for proper air circulation under and through the D/I Mux III.
Page 70: Wall Mounting
Chapter 3. Installation Figure 3-3. Table Mount Base Wall Mounting The D/I Mux III can be wall mounted when no rack mounting facilities are available. Research applicable building codes to ensure compliance. Mount the shelf where ventilation is best. Cooler operation of the unit will prolong the life of components and circuitry. Avoid wet or extremely humid locations.
Page 71 Chapter 3. Installation Basic Wall Mount Installation Without Wall Mount Bracket Detach both mounting brackets from the shelf by unfastening the four flat head #6-32 screws on each bracket. Rotate the brackets 90 degrees so that the bent-up flanges extend approximately one inch beyond the bottom of the shelf.
Page 72 Chapter 3. Installation Use these holes for securing To metal or wooden 2” x 4” studs Figure 3-6. Basic Wall Mount Fastening...
Page 73 Chapter 3. Installation Planning and Installation Off-premises connections: Telecommunication cables that leave the facility (off-premises wiring) can be subject to lightning and / or power surge conditions. Care must be taken that proper surge protection devices for such lines are installed prior to connecting them to a D/I Mux III multiplexer.
Page 74: System Cabling
Chapter 3. Installation Grounding: Protection against safety fault or surge current is provided by connecting the D/I Mux III chassis to the facility earth ground. Since both safety fault currents and surge events are conducted to earth ground by this connection, it should be made with a short, direct, heavy grounding conductor, # 10 AWG or heavier. If not grounded in this manner, an adequate ground may be obtained through the D/I Mux III mounting ears if the facility equipment rack is securely grounded to the facility earth ground via a heavy, direct conductor.
Page 75 Chapter 3. Installation CCU/AMCU 8-Slot Shelf Backup AMCU Front Pantel Figure 3-7. Containment of Radio Frequency Emissions...
Page 76 Chapter 3. Installation Figure 3-8 Backplane for Slot Voice and Data Shelf (F=Female, M=Male) (P/N 91620-308)
Page 77 Chapter 3. Installation Figure 3-9 Backplane for 12-Slot Voice and Data Shelf (F=Female, M=Male) (P/N 91620-312)
Page 78 Chapter 3. Installation Figure 3-10 Backplane for 24-Slot Voice and Data Shelf (F=Female, M=Male) (P/N 91620-324)
Page 79 Chapter 3. Installation...
Page 80: Power And Alarms
CAUTION! If connecting hot power, be certain to connect to the D/I Mux III system first and then to the DC power source. This minimizes the possibility of a hot wire becoming grounded. Coastcom does not recommend connecting live or hot power.
Page 81: Ac Power
Use an alarm fuse panel if several D/I Mux III systems or other devices are using the same DC power source. Without a fuse panel, one device failure can overload the DC power source, causing multiple failures. Contact Coastcom's Applications Engineering department to determine the appropriate fuse panel for a particular application.
Page 82 Chapter 3. Installation Locate the two DB-15 or RJ-48 connectors on the shelf backplane. They are labeled DS1/CSU T1-1 and DS1/CSU T1-2. See Figures 3-12 and 3-13 for details. For single channel bank mode, plug the T1 transmission line into the T1-1 connector on the shelf backplane;...
Page 83: T1 Cabling Considerations
Chapter 3. Installation T1 Cabling Considerations Connection of the D/I Mux III in channel bank mode to the T1 network is a DTE-to-DCE connection. Some examples of D/I Mux III-to-DCE connections are: Channel Service Units (CSUs), Smart Jacks, Fiber Optic Modems, and Fiber Multiplexers.
Page 84: Timing Sync I/O
Chapter 3. Installation Timing Sync I/O External synchronization can be achieved with a DB-9 female external Synchronous Input/Output (Sync I/O) connector. With it, the D/I Mux III can be configured for master or slave clock timing. (Refer to Figure 3-14.) Figure 3-14.
Page 85: Slot 2 Synchronization (Optional)
Chapter 3. Installation Table 3-4. Common Synchronization Frequencies Reference Clock Frequency (in Reference Clock Frequency Tolerance (+/- Hz) 8,000 0.26 9,600 0.31 56,000 1.81 64,000 2.07 128,000 4.15 256,000 8.29 768,000 24.87 1,536,000 49.74 Slot 2 Synchronization (Optional) The Slot 2 Synchronization feature allows data line cards to provide local timing for the D/I Mux III. A data line card plugged into card slot 2 is the external input used to produce a 1.544 MHz clock reference.
Page 86: Event Switch
Chapter 3. Installation Event Switch The event switch is a screw terminal marked labeled EMD (some cards are labeled EVNT) on the backplane terminal block. An event switch is also available on pin 9 of the SYNC I/O connector. Connect to the event terminal with standard 18- to 26-gauge wire. An event map change occurs when the event terminal is connected to the D/I Mux III ground.
Page 87: Voice Circuits
Chapter 3. Installation Figure 3-15. Voice/Data Jumpers Voice Circuits The 8-slot Universal and 12-slot D/I Mux III shelves have three 50-pin VF connectors, and the 24- slot shelf has six 50-pin VF connectors. They are designated P1, P2, and P3 on the 8-slot and 12-slot shelves, and P1, P2, P3, P4, P5, and P6 on the 24-slot shelf.
Page 88 Chapter 3. Installation Each 50-pin connector has two sets of pins for each line card slot, Channel A and Channel B. 2- Wire voice cards require the T and R connections. 4-Wire voice cards require T, R, T1, and R1 connections.
Page 89 Chapter 3. Installation Table 3-10. 50-Pin Connector Pin-Outs for the 24-Slot Shelf Card Slot Channel A Channel B R & T R1 & T1 M & E R & T R1 & T1 M & E P4 - 1/26 P5 - 1/26 P6 - 1/26 P4 - 13/38 P5 - 13/38...
Page 90 Chapter 3. Installation Table 3-11. 50-Pin Amphenol Connector With Jumper Set to VF Pair Circuit P1/P4 P2/P5 P3/P6 Bl/Wh T1R1 E&M Or/Wh T1R1 E&M Gr/Wh T1R1 E&M Br/Wh T1R1 E&M Sl/Wh T1R1 E&M Bl/Rd T1R1 E&M Or/Rd T1R1 E&M Gr/Rd T1R1 E&M Br/Rd...
Page 91 Chapter 3. Installation 50-Pin Voice Cable Installation Locate the 50-pin VF connectors on the shelf backplane. Connect VF lines to the 50-pin connectors. Position the jumper above and below the data connector corresponding to each voice card slot using the 50-pin connector. Place the jumper in the VF position. DB-25 Voice Cable Installation The DB-25 data connectors can be used for voice connections which require Type II and Type III signalling.
Page 92 Chapter 3. Installation Figure 3-17. Dual Channel Voice on DB-25 Female Connectors to Wire-Wrap Connections (Coastcom Cable Nos. 0600-0235/236/237) Use the following procedure for installing voice cable with the DB-25 connectors. Obtain an appropriate cable for the selected line card application.
Page 93: Data Circuits
Chapter 3. Installation Data Circuits Data connections are made via the DB-25 female backplane connectors on the D/I MUX III, shown below in figure 3-18. An adapter cable is needed to connect the Data Terminal Equipment (DTE) to the D/I Mux III.
Page 94: Digital Program Channels
Chapter 3. Installation Figure 3-20. V.35 Female Data Circuit Digital Program Channels Digital Program Channels (DPCs) can use the 50-pin voice connectors or the DB-25 connectors. They connect to Tip and Ring for transmit, and Tip 1 and Ring 1 for receive. Common Equipment and Line Card Installation All common equipment and line cards are installed in the same manner.
Page 95: Safety Precautions
Chapter 3. Installation Safety Precautions Observe the following safety precautions when installing the D/I Mux III system. • Never install telephone wiring during an electrical storm.1 • Never install telephone jacks in wet locations unless the jack is specifically designed for wet locations.
Page 96 Chapter 3. Installation Figure 3-21. 8-Slot Shelves (Front View) P/N 91620-308 and 91319-608 Figure 3-22. 12-Slot Shelf (Front View) P/N 91620-312 Figure 3-23. 24-Slot Shelf (Front View) P/N 91620-324...
Page 97: Strobe Units
Chapter 3. Installation Strobe Units The Lower Strobe Unit (P/N 30307-104A) provides strobe timing information for 8-slot shelves, 12-slot shelves, and the lower 12 card slots in a 24-card slot shelf. The Lower Strobe Unit has eight active option switches (Figure 3-18), any of which can be set for one of the eight preconfigured maps.
Page 98: Common Control Unit
Chapter 3. Installation Common Control Unit The Common Control Unit (CCU) is the major logic control for the D/I Mux III system. The CCU directs the other common equipment, and is the link to the system control (COM) port. See Figure 3-19 for a front and side view of the CCU.
Page 99: Advanced Multiplexer Control Unit (Amcu)
Mux III. With W2 set to the bottom position, the D/I Mux III is controlled by standard terminals using ASCII code. With W2 set to the top position the D/I Mux III is controlled with Coastcom proprietary language. Front Panel LEDs Front panel Light Emitting Diodes (LEDs) indicate the current status of the CCU.
Page 100 Chapter 3. Installation Figure 3-26. Advanced Multiplexer Control Unit - Front Panel The AMCU is a two-card assembly comprised of a standard CCU board and a 32-bit processor sub-board. The sub-board is required for SNMP capability, and provides the interface between all line cards and the system operator.
Page 101 Chapter 3. Installation LEDs Four front panel Light Emitting Diodes (LEDs) indicate status during the CCU/AMCU initialization process. The control terminal of the D/I Mux III also displays the indicator status. See Table 3-6 for AMCU LED indications. Table 3-6. AMCU Front Panel LED Indications LED Action Indication ACO blinks fast...
Page 102 Chapter 3. Installation Backplane The AMCU backplane interface provides the physical connections for the RS-485 half- duplex provisioning bus and the control terminal asynchronous serial channels. Power for the AMCU is also delivered through the backplane. Caution! While the AMCU connects to the backplane via the standard 56-pin card edge connector, care must be taken to ensure that the MCU is inserted only into the slot marked “CCU or AMCU.”...
Page 103 Chapter 3. Installation See Figure 3-21 for pin-out of Ethernet 10Base-T and SLIP/PPP ports. Figure 3-27. Ethernet and SLIP/PPP Port Pin-Outs...
Page 104: Line Interface Units
Chapter 3. Installation Line Interface Units The Line Interface Units (LIUs) give the D/I Mux III Channel Bank, Drop-and-Insert, and Dual Channel Bank (DCB) capabilities when used in conjunction with the CCU/AMCU. The LIUs select T1 line coding, framing, and alarm options. Select the options through software whenever possible.
Page 105 On an option switch power-up, the D/I Mux III is configured from the option switches on LIU A. Use Figure 3-22 (above) and Table 3-8 (on the following page) to set operation with the option switches. (Coastcom recommends configuring both LIUs with the same settings.)
Page 106: T1 Interfaces
Operation for more information on the SC command. T1 Interfaces The two types of T1 interface that can be used in a D/I Mux III system include the Dual DSX-1 Interface, which transmits and receives a basic DSX-1 signal, and the Dual CSU Interface which allows the D/I Mux III to perform the functions of a Channel Service Unit (CSU).
Page 107 Chapter 3. Installation The Dual Standard DSX-1 Interface, Model 30118-101, or the Dual Enhanced DSX-1 Interface, Models 30118-102 and 30118-112, interconnect the incoming and outgoing T1 streams of the D/I Mux III. The units also provide signal conditioning to compensate for the variations in cable lengths between the D/I Mux III and the DSX-1 cross-connect point or T1 transmission equipment.
Page 108 Chapter 3. Installation Dual CSU Interface The Dual CSU Interface offers a T1 interface, or a DSX-1 interface, with special test loopback capabilities between the T1 transmission line and the equipment. It is available in three versions. • P/N 30318-101 with interface T1 (T1-1) and DSX-1 (T1-2) •...
Page 109 Chapter 3. Installation CAUTION! The Dual CSU Interface should not be unplugged after initial installation. Notify the local Telco before disconnecting this unit, or changing any switch settings. Refer to the FCC and Telephone Company Requirements and Procedures section, preceding the Table of Contents in this manual for further information. Refer to Figure 3-24 for front and side views of the Dual CSU Interface Unit.
Page 110: Power Supply
Coastcom’s Applications Engineering group for a power requirements evaluation. Except where noted, the power matrix tables are for all D/I Mux III shelves in a nominal 0°- 50° C environment.
Page 111 Chapter 3. Installation Table 3-12. Maximum Data Line Cards Power Matrix for 24-Slot Shelf -48 V -48 V -24 V 110 V AC/DC Redundant DC Redundant Redundant Smart AC Power Power Supply DC Power DC Power Power Supplies 30338-102 Supply Supply Line Cards Supply...
Page 112 Chapter 3. Installation Table 3-13. Maximum Voice Line Cards Power Matrix for 24-Slot Shelf -48 V -48 V -24 V AC/DC Redundant DC Redundant DC Redundant DC 110 V Power Power Supply Power Supply Power Supply Smart AC Supplies 30338-102 30338-102 30314-101 Line cards...
Page 113: Dc Power Unit (P/N 30338-102 And 30338-902)
Chapter 3. Installation Table 3-14. Nominal/Maximum Power Consumption Matrix (W/BTUs)** Chassis Shelf Fully Outfitted (Nominal) Shelf Fully Outfitted (Maximum) (Slot) Voltage BTU/Hr BTU/Hr 110 V AC 0.54 0.75 110 V AC 0.67 1.00 110 V AC 1.04 1.50 -48 V DC 1.25 1.77 -48 V DC...
Page 114 Chapter 3. Installation Table 3-15. Power Supply Fuses (P/N 30338-102) Fuse Amperage Color Power Supply Designation Designation GMT 1 Gray -48 AB GMT 3 Blue -48 SB GMT 4 White/Brown -48 DC -48 V DC Power Supply Installation (P/N 30338-902) Note: Do not fully seat the power supply until wiring and other common equipment is in place.
Page 115: 110 V Ac Power Unit
Chapter 3. Installation 110 V AC Power Unit Using the 30315-505 AC power supply simplifies installation of D/I Mux III at customer premises. This unit is a self-contained single-slot power supply that provides all of the voltages necessary to operate a D/I Mux III - except ringing voltage. When configured with FXS feature cards, order modular Ringing Generator 30333-101.
Page 116 Chapter 3. Installation 110 V AC Power Supply Installation Following is the procedure for installing the 110 V AC power supply. Follow the steps in the order given. Refer to Figure 3-25 for jumper locations on the power unit. Remove any nut which may be attached to the back of the power supply, or on the grounding lug which may have been installed there for shipping purposes.
Page 117: Smart 110 V Ac Power Supply
Chapter 3. Installation Smart 110 V AC Power Supply (P/N 30308-102) (this product has been put on “end- of-life” status) The older model 110 V AC Power Supply (P/N 30308-102) is a fully self-contained unit that provides all of the voltages necessary to operate any type of D/I Mux III configuration. It operates from 110 V commercial AC power.
Page 118 Chapter 3. Installation Smart 110V Power Supply Installation Following is the procedure for installing the Smart 110 V AC power supply. Follow the steps in the order given. Refer to Figure 3-26 for jumper locations on the power unit. Figure 3-32. Smart 110 V AC Power Unit (Front Panel and Bottom View) Set Switch S1 to enable or disable the Ringing Generator as desired.
Page 119: Transmission Connection
Chapter 3. Installation Ensure that the terminal block's protective covers are in place after installation. Voltages will be marked on the terminal blocks. WARNING! The ringer provides a constantly accessible 95 V AC on the backplane, so use caution whenever the system is powered.
Page 120: Line Card Installation
Upon completion of self-test, the initialization routine begins, during which the LIU LEDs cycle on and off. Note: Depressing the BYP button during power-up causes the CCU/MCU to “bypass” the checksum test. Configuring the D/I Mux III System Refer to Chapter 4. Configuration and Operation for information on D/I Mux III software configuration.
Page 121: Chapter 4. Configuration And Operation
Chapter 4. Configuration and Operation Chapter 4. CONFIGURATION AND OPERATION This chapter describes how to configure the D/I Mux III after the hardware has been installed. The chapter is divided into three sections as follows: • The Overall System Command Organization, with figure number references, is listed in Figure 4-1. •...
Page 122 Chapter 4. Configuration and Operation CCU System Access Screen - Figure 4-2 AC (Access CCU - D/I Mux III User Submenu) - Figure 4-6 ⎪ ├──Shelf Configuration ⎪ (Display Shelf Configuration) - Figure 4-11 ⎪ (Set Shelf Configuration) - Figure 4-44 ├──System Parameters ⎪...
Page 123: Setup And Programming Order
Chapter 4. Configuration and Operation Setup and Programming Order This section lists the programming commands in the order recommended for configuration and operation of the network and local systems. The two letter commands, and appropriate reference figure numbers, are included. If this is the first time the shelf is to be programmed, or if it needs to be reset to factory defaults, do an NVRAM clear.
Page 124: Screen Display And Data Entry
Each system function is accessed by a two-letter command at either the CCU system access screen, or the MCU Main Menu screen for D/I Mux III parameters (AC). For the D/I Mux III system CCU, the first letter is usually D for display, or S for set or modify. For the MCU, the first letter is usually V for view, or M for modify or set, and R for remove.
Page 125: Obtaining System Access
At initial startup, it is not necessary to enter a password. Press [Enter]. To access the Main Menu with a Common Control Unit (CCU), the screen in Figure 4-2 will appear. Type ? and press [Enter]. Coastcom 1141 Harbor Bay Parkway Alameda, CA 94502...
Page 126 Chapter 4. Configuration and Operation Welcome to the Coastcom D/I III Configuration System Copyright 1995 - Coastcom, Alameda, California 13:15:23 06/08/95 Access Level is: 1 Type ? for Help 13:15:28 ---------------------[ AMCU Main Menu ]--------------------- 06/08/95 LOCAL PARAMETERS NETWORK PARAMETERS...
Page 127 Chapter 4. Configuration and Operation Welcome to the Coastcom D/I Mux III Configuration System Copyright 1995 - Coastcom, Alameda, California 13:15:52 06/08/95 Access Level is: 2 Type ? for Help 13:15:55--------------------[ AMCU Main Menu ]--------------------- 06/08/95 LOCAL PARAMETERS NETWORK PARAMETERS...
Page 128: Ac - Accessing The Ccu/D/I Mux Iii User Screen
Chapter 4. Configuration and Operation AC - Accessing the CCU/D/I Mux III User Screen To access the D/I Mux III CCU user sub-menu screen, from the AMCU Main Menu, type AC and press [Enter]. The screen shown in Figure 4-6 appears. 08:42:57 ----------------------[ Menu ]----------------------- 11/28/95 ALARMS SYSTEM PARAMETERS...
Page 129: Amcu Configuration
Chapter 4. Configuration and Operation AMCU Configuration Prior to use of the SNMP function of the AMultiplexer Control Unit (AMCU), the AMCU must be configured via the local RS-232 port with an ANSI video display terminal (VDT), or a personal computer (PC).
Page 130 Chapter 4. Configuration and Operation ] CL Copy Line Card Configuration Source Slot Number [1..12] 1 Destination: Slot Range *) All Slots [1..12] 2 Are You Sure? Y) Yes N) No [Y/N] Figure 4-8. Copying Line Card Configuration In the example shown in Figure 4-8, the source slot number is the card configuration to be copied from (slot 1), and the destination slot number (slot 2) receives the copied line card configuration.
Page 131: Cm - Copying The Map Matrix
Chapter 4. Configuration and Operation CM - Copying the Map Matrix This procedure assigns the transmission timeslots to the line card slots. Use the matrix map to plan the matrix configuration. If the planned map matrices have some common channel assignments, the Copy Map (CM) matrix procedure is a faster way to create a new map by copying an existing (complete) matrix to another matrix map, and then editing the data.
Page 132: Da - Displaying Alarms
Chapter 4. Configuration and Operation DA - Displaying Alarms Enter DA to Display the T1 Alarm data (as depicted in Figure 4-10). The Card Slot column indicates which card generated the alarm. The Alarm column indicates the type of alarm it generated. The Level column shows Major, Minor, or Info alarms based on the severity of the alarm.
Page 133: Dc - Displaying Shelf Configuration
Chapter 4. Configuration and Operation DC - Displaying Shelf Configuration The DC command Displays the shelf Configuration screen (Figure 4-11). The display will reflect the current shelf configuration. The revisions will vary depending on the release of the product purchased. If a Dual DSX-1 Interface is installed, or if a Facility Data Link Processor (FDLP) card is not installed, an empty card slot message will appear.
Page 134: Dd - Displaying Line Card Data Configuration
Chapter 4. Configuration and Operation DD - Displaying Line Card Data Configuration Enter DD to Display the line card Data configuration screen (Figure 4-12). In the example below, the system displays the last card slot operated (which in the example is card slot 5). The current card under observation is in card slot 3, and it is an intelligent Dual 4-Wire channel card.
Page 135: Dh - Displaying Alarm History
Chapter 4. Configuration and Operation DH - Displaying Alarm History Enter DH to Display the alarm History log (Figure 4-13). The alarm log lists the last 50 alarms, with the most recent listed in the number 1 position. Pertinent line card and alarm data are included. ] DH 10:39:38------------------- [ Alarm Log ] --------------------03/08/95 Time...
Page 136 Chapter 4. Configuration and Operation DL - Displaying Line Card Table Enter DL to Display the installed Line card table (Figure 4-14). Smart and non-intelligent cards specified through use of the Set Line card configuration (SL) command, are displayed. Active data rates are shown for all mapped cards.
Page 137: Dm - Displaying Map Matrix
Chapter 4. Configuration and Operation DM - Displaying Map Matrix Enter DM to Display a Map matrix. At the prompt, enter the number of the desired map. In the example below, map 1 has been selected. At the next prompt, enter 1 to display the Line Card Map. (Figure 4-15 shows the entire prompt sequence after DM.) ] DM Display Map Number...
Page 138 Chapter 4. Configuration and Operation The DM command is also used to display the map matrix DS0 Assignment Map. At the Display Map Number prompt, enter the number of the desired map. In the example below, map 2 has been selected. At the Display prompt, enter 2 to display the DS0 Assignment Map.
Page 139: Dn - Displaying The Current Working Map
Chapter 4. Configuration and Operation DN - Displaying the Current Working Map Enter DN to display the current working map number (Figure 4-17). ] DN Current Working Map: 1 Figure 4-17. Displaying the Current Working Map DP - Displaying System Parameters Enter DP to Display system Parameters, as shown in Figure 4-18.
Page 140: Ds - Displaying Clock Source
Chapter 4. Configuration and Operation DS - Displaying Clock Source Enter DS to Display the clock Source, as depicted in Figure 4-19. Different alarms trigger various clock sources. Clock source is set with the Set clock Source (SS) command. The example in Figure 4-19 shows the clock sources for drop-and-insert mode. The asterisk shows the present mode of operation, with a local alarm on T1-1.
Page 141: Dt - Displaying The Current Map Table
Chapter 4. Configuration and Operation DT - Displaying the Current Map Table The map that currently controls the matrix is called the working map. Only maps that are enabled can be switched to a working map. The four types of maps include time-driven, event-driven, alarm-driven, and manual maps.
Page 142: Dv - Displaying Smart Ac Power Supply Parameters
Chapter 4. Configuration and Operation DV - Displaying Smart AC Power Supply Parameters Enter DV to Display the parameters of the 110 Volt Smart AC power supply (P/N 30308-102). Note that the option to select DV is only available when a Smart AC power supply is installed in the D/I Mux III system.
Page 143: Dw - Displaying The Current Password
Chapter 4. Configuration and Operation DW - Displaying the Current Password Enter DW to Display the current passWord (Figure 4-22). ] DW 10:48:42 ------------------ [ Passwords ]------------------- 03/08/95 Level Password --------------------------------------------------------------------- NetMan Tech1 --------------------------------------------------------------------- Figure 4-22. Displaying the Current Password Note: Only a Level 1 password user will be able to display the passwords screen.
Page 144: Lo - Logging Off
Chapter 4. Configuration and Operation LO - Logging Off Type LO to Log Off (Figure 4-24), and return to the Main Menu. This command may also be used to determine if there is a previous Level 1 password. The following example shows the response to a user without Level 1 password access.
Page 145: Mg - Modifying/Setting The Gateway Address
Do you want to define a gateway? [N] y Enter the Gateway IP Address [None]: 130.1.10.50 Stand by to reboot. Confirm? [N] y Password: Welcome to Coastcom D/I Mux III Configuration System Copyright (c) 1995 - Coastcom, Alameda, California 15:15:37 06/08/95 Access Level is: 1...
Page 146: Mi - Modifying/Setting The Local Ip Address
Do you want to continue? [N] y Enter Local IP Address [127.0.0.1]: 130.1.10.99 Stand by to reboot. Confirm? [N] y Password: Welcome to Coastcom D/I Mux III Configuration System Copyright (c) 1995 - Coastcom, Alameda, California 15:18:42 06/08/95 Access Level is: 1...
Page 147: Ml - Modifying/Setting Slip Parameters
Chapter 4. Configuration and Operation ML - Modifying/Setting SLIP Parameters From the AMCU Main Menu, use the ML command to set SLIP feature parameters, as depicted in Figure 4-28. Note that the SLIP and Ethernet ports should have different IP addresses. Consult the local LAN administrator for assistance with these address assignments.
Page 148: Mm - Modifying/Installing The Manager
Chapter 4. Configuration and Operation MM - Modifying/Installing the Manager From the AMCU Main Menu, use the MM command to run the Modify/install Manager function, as shown in Figure 4-29. Refer to Appendix G. SNMP for access option definitions. The configuration shown in the example below allows an SNMP manager installed on a workstation with an IP Address of 130.1.10.25 to have Set-and-Get access, and to receive Traps, all with a community string of “public”.
Page 149: Mp - Modifying/Installing An Mcu Password
Chapter 4. Configuration and Operation MP - Modifying/Installing an AMCU Password There are three levels of AMCU passwords that allow the user to either control or observe different operating system levels. Up to eight passwords may be assigned. (There is no default password.) •...
Page 150: Ms - Modifying/Installing The Subnet Mask
Chapter 4. Configuration and Operation MS - Modifying/Installing the Subnet Mask From the AMCU Main Menu, type MS to Modify, or install, the Subnet mask. The screen shown in Figure 4-31 will appear. The Subnet Mask modifies which portion of the IP Address is interpreted as the network portion.
Page 151 Chapter 4. Configuration and Operation MT - Modifying Keyboard Time-Out From the AMCU Main Menu, selecting the MT command from the AMCU Main Menu activates the Keyboard Time-Out function, as depicted in Figure 4-32. Use this screen to set how many minutes of keyboard inactivity may elapse before the work session will automatically end, allowing another session to be opened.
Page 152: Od - Operate Diagnostics Menu
Chapter 4. Configuration and Operation OD - Operate Diagnostics Menu Use the OD command to access the Operate line card Diagnostics menu, as depicted in Figure 4-33. Depending upon the T1 interface, there may be different options presented for shelf control selections. Refer to Chapter 5.
Page 153: Ol - Operate Line Card Diagnostics Menu
Chapter 4. Configuration and Operation OL - Operate Line Card Diagnostics Menu Use the OL command to display the Operate Line card diagnostic menu, as depicted in Figure 4-34. Enter the slot number of the card selected for diagnostic testing. The menu will differ, depending upon the card being tested.
Page 154 Chapter 4. Configuration and Operation Upon selection of one of the displayed options, the system prompts for an indication of whether the A or B channel is intended for modification. If option 5 is selected, the display in Figure 4-35 appears. Current Status Ch.
Page 155: Pm - Fdl Monitor
Chapter 4. Configuration and Operation PM - FDL Monitor If a Facility Data Link Processor (FDLP) is included in the multiplexer, enter PM to begin Performance Monitoring, as shown in Figure 4-37. For more detail on this function, refer to the FDLP User’s Manual. ] PM 10:40:23--------------- [ PERFORMANCE MONITOR ]--------------- 03/08/95 Select Direction...
Page 156: Q - Quit Command
4-4, and 4-5). To begin a new work session, enter an installed password. If no passwords are installed, simply press [Enter] to begin a new session. Password: Welcome to the Coastcom D/I Mux III Configuration System Copyright 1995 - Coastcom, Alameda, California 08:41:54...
Page 157: Rp - Removing/Erasing Passwords
Chapter 4. Configuration and Operation RP - Removing/Erasing Passwords From the MCU Main Menu use the RP command to Remove a Password, as shown in Figure 4-40. ] RP Enter Password to Erase: testla ** Password Erased ** ]Figure 4-40. Removing/Erasing Passwords SB - Setting the Error Rate The Set Bit error rate (SB) command determines the alarm function by setting the Error Rate Test (ERT) Alarm.
Page 158 Chapter 4. Configuration and Operation The set point is the value (the mantissa) raised to the specified power (exponent) at which alarms are generated. To change the ERT set point or threshold, enter 1 as shown in Figure 4-42. T1-1 Alarm Set Pt. Mantissa (1..9) Exponent (3..6) Figure 4-42.
Page 159: Sc - Setting Shelf Configuration
Chapter 4. Configuration and Operation SC - Setting Shelf Configuration Shelf configuration consists of the following optional settings. • Source of shelf settings after power-up • Source of strobe settings after power-up • Mode of operation • Shelf timing • Frame mode •...
Page 160 Chapter 4. Configuration and Operation ALPS Protection 1) Enabled 2) Disabled Figure 4-45. Enabling ALPS Protection The system next prompts for a choice of shelf timing and mode of operation (as depicted in Figure 4-46). The master site must be set to Local; all other sites must be set to Loop. Shelf Timing L) Loop C) Local...
Page 161 Chapter 4. Configuration and Operation If single channel bank or dual channel bank is selected, the system queries as to whether timing should be loop or local shelf timing (Figure 4-48). Shelf Timing L) Loop C) Local Figure 4-48. Selecting Shelf Timing When Loop timing is selected for dual channel bank mode, the system prompts with the following choices as shown in Figure 4-49.
Page 162 Chapter 4. Configuration and Operation Zero Suppression Mode B) B8ZS 7) Bit-7 Stuffing T) Transparent Figure 4-51. Specifying Zero Suppression Mode Remote alarms (D/I Mux III sending yellow alarms) can be directed. In channel bank mode, the choices are T1-1 REM Alarm output, or none; in dual channel bank mode, the choices are T1-1, or none, and T1- 2, or none.
Page 163 Chapter 4. Configuration and Operation T1-1 REM Alarm Output N) None 1) T1-1 2) T1-2 B) Both T1-2 REM Alarm Output N) None 1) T1-1 2) T1-2 B) Both Apply Changes Y) Yes N) No [Y/N] Y Figure 4-52. Directing REM Output...
Page 164: Sl - Setting Line Card Configuration
Chapter 4. Configuration and Operation SL - Setting Line Card Configuration All system line cards must be configured prior to use. The system identifies software-controlled line cards, progressing through a configuration menu for each specific line card. The example in Figure 4-53 depicts the Set Line card configuration function for a hardware-configured Digital Program Channel (DPC).
Page 165: Sm - Setting/Editing A Map Matrix
Chapter 4. Configuration and Operation SM - Setting/Editing a Map Matrix Select the desired map number (1-7 of the available map-capable storage options), and enter the direction to be edited. In channel bank and ALPS modes, Edit Direction does not apply, and is not given as an option.
Page 166 Chapter 4. Configuration and Operation To edit a line card slot, first enter the slot number to be edited. The channel card will supply the card type and model information, which will be displayed on the screen, along with the existing line card map (if any).
Page 167 Chapter 4. Configuration and Operation Line Card Slot Number (1A..24D) [Quit] Card Type :SDCU Card Model number :30351-105 DS0: SLOT 1 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 --------------------------------------------------------------------------- --------------------------------------------------------------------------- DS0 Range (1-24) *) All DS0s C) Clear All DS0s...
Page 168: Sn - Setting The Working Map
Chapter 4. Configuration and Operation To “Quit” at the Line Card Slot Number prompt, simply press [Enter]. Figure 4-57 depicts the prompts that appear when quitting the line card assignments. The updated line card map and DS0 assignment map are shown, as a review of the information that has just been entered. In the DS0 assignment map, the x designates a through DS0.
Page 169: So - Setting The Communications Configuration
Chapter 4. Configuration and Operation ] SN Current Working Map: 1 New Working Map Number (1..7) 1 Are You Sure? Y) Yes N) No [Y/N] Figure 4-58. Setting the Working Map SO - Setting the Communications Configuration Applicable only to the CCU portion of the system, and not supported by the MCU, the SO command is used to display and set the communications configuration (Figure 4-59).
Page 170 Chapter 4. Configuration and Operation System Label - Enter as desired. System Date and Time - Initial entry of real-time clock data. T1 Alarm Processing - Alarm routing to either T1-1 or T1-2; Carrier Group alarm release and delay time options;...
Page 171 Chapter 4. Configuration and Operation ] SP Enter System Operation Parameters Use Installed Line Cards to Cross-check Map Display/Edit Y) Yes N) No [Y] Y Shelf Size [24] System ID System Label Set System Date and Time Y) Yes N) No Set T1 Alarm Processing Y) Yes N) No...
Page 172: Sr - Setting The Com Port Data Rate
Chapter 4. Configuration and Operation SR - Setting the COM Port Data Rate Use the SR command to Set the COM port data Rate, as depicted in Figure 4-61. Setting the data rate on the CCU motherboard will automatically change the data rate on the MCU sub-board to a matching rate.
Page 173: Ss - Setting The Clock Source
Chapter 4. Configuration and Operation SS - Setting the Clock Source Enter SS to Set the clock Source (Figure 4-62). (Coastcom recommends leaving the internal clock set to factory defaults.) In drop-and-insert mode/normal operation (No Alarm), the system always uses the received T1 clocks for timing sources.
Page 174: St - Setting/Editing The Map Table
Chapter 4. Configuration and Operation Ext Slot-2 is the clock received from a line card in slot 2 of the D/I Mux III. Ext DB-9 is a connector on the back of the D/I Mux III shelf (SYNC I/O) that will accept TTL, or differential signals, as a timing source.
Page 175: Sw - Setting/Installing Ccu Passwords
Chapter 4. Configuration and Operation ] ST Edit Map Table Map Number Map 3 Label (up to 10 Characters) [Map 3] Enter Type A) Alarm E) Event T) Time M) Manual Enable Map Y) Yes N) No One Time Use Y) Yes N) No [Y] N...
Page 176 Chapter 4. Configuration and Operation Use the SW command to Set/install a CCU passWord, as shown in Figure 4-65. Actual password entries will not be visible upon entry. There are three levels of passwords that allow the user to either control or observe different operating levels of the system.
Page 177: Vm - Viewing Manager Configuration
• IP Address (Internet Protocol): Initially set by Coastcom prior to shipment as a special loopback test address only, an IP Address change is required for network operation. If operating on a private network, a system administrator should assign the address as appropriate.
Page 178: Vp - Viewing Passwords
Chapter 4. Configuration and Operation ] VN 15:14:36 ---------- [ Network Parameters ] ---------- 06/08/95 MAC Address: 00:A0:70:00:00:02 IP Address: 127.0.0.1 Subnet Mask: 255.255.255.0 Default Gateway: None SLIP Parameters: Local IP Address: 130.1.10.98 Peer IP Address: 130.1.10.15 MTU: 1006 Data Rate: 9600 -------------------------------------------------------------- Figure 4-67.
Page 179: Vr - Viewing Software Revision Status
Chapter 4. Configuration and Operation VR - Viewing Software Revision Status From the MCU Main Menu, enter the VR command to View the Revision number of the current MCU operating system software,. The revision screen is then displayed as depicted in Figure 4-69. During this display process, the CCU may not be accessed until communication is re-established.
Page 180: Za - Clearing Alarm Count
Chapter 4. Configuration and Operation ZA - Clearing Alarm Count Use the Zero Alarm (ZA) count command to clear the alarm records in the Display Alarm (DA) list that are no longer active (refer to Figure 4-10 for the DA screen). It also writes to the history file that alarms have been reset, as reflected in the Display Alarm History (DH) screen (Figure 4-13).
Page 181: Chapter 5. Diagnostics
Chapter 5. Diagnostics Chapter 5. DIAGNOSTICS D/I Mux III system diagnostics include alarms, power-up sequences, test loopbacks, and individual circuit testing. The T1 alarms are the standard T1 Bell System alarms; local, remote, and Carrier Group Alarm (CGA). Optioned with a Dual CSU Interface, the D/I Mux III can initiate a T1 bypass, T1 CSU loopback, and also respond to the network's T1 CSU loopback request.
Page 182: T1 Alarms
Bipolar Violations, Bit 7 Zeros Suppression, 0-Density, and All Ones. These alarms are displayed on the Line Interface Unit (LIU) front panel Light Emitting Diodes (LEDs), and in the D/I Mux III system software. If one of these primary T1 alarms activates, an inspection of the T1 cable connections should be conducted, and the T1 carrier company should be called.
Page 183: B7 Alarm
Chapter 5. Diagnostics B7 Alarm The Bit 7 Zeros Suppression Alarm (B7) LED illuminates if the D/I Mux III has been programmed for bit seven zero suppression. While historic, this type of zero suppression is rarely used, and should not be used for data circuits. BPV Alarm The Bipolar Violations Alarm (BPV) LED illuminates whenever the LIUs detect a series of bipolar violations.
Page 184: Alarm Dialout
Chapter 5. Diagnostics Table 5-1. Alarm Contacts and Alarm Cut-Off (ACO) Alarm Audible Contact Visual Contact Minor Contact Major Closed Closed Open Major with ACO Open Closed Open Minor Open Open Closed Alarm Dialout The D/I Mux III can report new alarm conditions to remote locations by dialing out through a port expander and a modem.
Page 185: Power-Up Sequence
NVRAM power-up clears all shelf, line card, and password information. Troubleshooting When a fault is apparent within the D/I Mux III system, board-level troubleshooting procedures further isolate the problem. When the fault is isolated to one or more unit assemblies, replace each suspected unit with a known good spare until the fault clears.
Page 186 Chapter 5. Diagnostics Table 5-2. LED INDICATIONS and PROBLEMS POSSIBLE PROBLEMS / SOLUTIONS T1 span is set to a different frame mode than the D/I Mux III. Access Set shelf Configuration (SC), and change frame mode. With a LOC alarm, for Models 30309-104/114, and 30309- 105/115, the LED colors may be Red (R), Yellow (Y), Green (G), or slight variations on the LED color depending on version.
Page 187: System-Level Troubleshooting
If a T1 failure occurs, loop the T1 at the backplane connector by performing the following steps. This will isolate the problem to either the D/I Mux III system, or to another part of the network. Remove the T1 cable from the T1-1 connector.
Page 188: Common Equipment And Line Card Testing
Removal of the shorted card will allow the voltages to restore themselves and will extinguish the power supply FAIL LED. Check the D/I Mux III system software programming using the Display line Card configuration (DC), Display system Parameters (DP), and related commands.
Page 189: Line Interface Units (Lius)
Chapter 5. Diagnostics Line Interface Units (LIUs) This section contains illustrations of the Line Interface Unit (LIU) front panels (refer to Figure 5-1) and a description of the LIU Light Emitting Diode (LED) indications (see Table 5-3). Figure 5-1. Line Interface Units Front Panels P/N 30309-104A and 30309-114A...
Page 190 Chapter 5. Diagnostics Table 5-3. LIU Front Panel Legend Indication Classification Loss of T1 framing for more than Major 450 milliseconds B2 = 0 for all received DS0s, or Major yellow alarm in FDL Trunk conditioning; activated 2.5 Informational seconds after loss of frame Framing errors on incoming T1 Major Bit 7 stuffing active...
Page 191: T1 Transmission Tests
Chapter 5. Diagnostics T1 Transmission Tests T1 Transmission Tests cover initial testing for channel bank, drop-and-insert, and dual channel bank operation. Testing with the Dual Standard DSX-1 Interface Unit, Dual Enhanced DSX-1 Interface Unit, and Dual CSU Interface are described for each mode of operation. The initial testing of the D/I Mux III verifies the following system responses: •...
Page 192 Chapter 5. Diagnostics Figure 5-2. DB-15 Male T1 Loopback Connector Figure 5-3. RJ-48 T1 Loopback Connector...
Page 193 Chapter 5. Diagnostics An understanding of the jackfields on the Dual Enhanced DSX-1 Interface and Dual CSU Interface is helpful when performing T1 transmission testing. Refer to Figures 5-4 and 5-5 for details on the operation of the jackfields. T1 test equipment usually accesses the system and network through a jackfield.
Page 194 Chapter 5. Diagnostics Figure 5-5. Dual CSU Interface - Jackfield Block Diagram (part numbers 30318-101, 30318-102, 30318-103)
Page 195: Single Channel Bank Mode
Chapter 5. Diagnostics Single Channel Bank Mode Use the following procedures to test the D/I Mux III in channel bank mode (and not yet in the T1 network). Select single channel bank operation with local timing, as described in Chapter 4. Configuration and Operation.
Page 196 Chapter 5. Diagnostics Bypass Switch and Response Press the BYP (bypass) switch on the CCU/AMCU. The BYP LED on the CCU/AMCU turns on, and the LOC LED on LIU B turns off. The CGA LED on LIU B remains lit. The ACO LED on the CCU/AMCU turns off. The FRM LED on LIU B turns off.
Page 197: Drop-And-Insert Mode Tests
Chapter 5. Diagnostics Drop-and-Insert Mode Tests Use these procedures when installing the D/I Mux III multiplexer for drop-and-insert operation. D4 channel banks, or D/I Mux IIIs in channel bank mode, are required at both ends of the T1 links to perform these procedures. The alarm function tests require a jackfield. Note: Single channel bank mode testing should be performed prior to drop-and-insert mode testing.
Page 198: Software Controlled Loopback Tests
Chapter 5. Diagnostics Local Alarm Test Break the T1 input path by placing a bantam plug in the Dual Enhanced DSX-1 Interface A IN EQ jack, or the Dual CSU Interface T1-2 EQ IN jack. The FRM LED and the LOC LED on LIU A light. After approximately 2.5 seconds, the CGA LED illuminates, generating a remote alarm.
Page 199: Loopback Tests
LIUs. Loopback Tests The following sections describe, and depict, the various D/I Mux III system loopbacks. Refer to the software diagnostics portion of this chapter for instructions on how to initiate and remove these loopbacks.
Page 200: Channel Bank: Bypass
Chapter 5. Diagnostics Channel Bank: Bypass In channel bank bypass mode, the PCM span B input path to LIU B is broken, and replaced with the output from LIU A. From the output of LIU B, an Alarm Indication Signal (AIS) is sent to the output of span A.
Page 201: Channel Bank: Line Loopback
Chapter 5. Diagnostics Channel Bank: Line Loopback Line loopback is set in response to receiving the “Line Loop Set” code on a span's input, or via software. Pulse Code Modulation (PCM) arriving at the input is looped back to the opposite span's output.
Page 202: Channel Bank: Payload Loopback
Chapter 5. Diagnostics Channel Bank: Payload Loopback Payload loopback is initiated from the D/I Mux III software interface. In payload loopback, the LIUs are included in the data path. Incoming PCM from span B is sent to the input of LIU B, then from the output of LIU B to the input of LIU A, and finally from the output of LIU A to the output of span A, as depicted in Figure 5-10.
Page 203: Drop-And-Insert: Normal Operation
Chapter 5. Diagnostics Drop-and-Insert: Normal Operation Under normal drop-and-insert operation, the Dual CSU Interface routes incoming PCM from span B to the input of LIU B, and sends PCM from the output of LIU B to the output of span B. Incoming PCM from span A is sent to the input of LIU A, and PCM from the output of LIU A is sent to the output of span A.
Page 204: Drop-And-Insert: Bypass
Chapter 5. Diagnostics Drop-and-Insert: Bypass Bypass mode removes the D/I Mux III from the T1 line by bypassing the incoming T1 PCM around the LIUs. The Dual CSU Interface receivers and line buildouts are left in line to provide the correct levels on the T1 line. Within the D/I Mux III shelf, the output of LIU B is connected to the input of LIU A, and the output of LIU A is connected to the input of LIU B, as illustrated in Figure 5-12.
Page 205: Drop-And-Insert: Line Loopback
Chapter 5. Diagnostics Drop-and-Insert: Line Loopback Line loopback is set in response to receiving the “Line Loop Set” code on a span's input. PCM arriving at the input is looped back to the opposite span's output. The LIUs are not in the PCM path.
Page 206 Chapter 5. Diagnostics Drop-and-Insert: T1-2 Line Loopback Line Loop Set code received on the input of span A causes span A input PCM to be looped back out span B before reaching the LIUs, as well as passing it on to the input of LIU A.
Page 207 Chapter 5. Diagnostics Drop-and-Insert: T1-1 and T1-2 Line Loopback Line Loop Set code received on span B input causes PCM to be looped back out span A's output, as well as being passed on to the input of LIU B. The PCM from the output of the LIU A is blocked.
Page 208: Drop-And-Insert: Payload Loopback
Chapter 5. Diagnostics Drop-and-Insert: Payload Loopback Payload loopback is initiated from the D/I Mux III software interface. In payload loopback, the LIUs are included in the data path; line loopback does not include the LIUs. In payload loopback, the loopback occurs after rather than before the LIUs. Drop-and-Insert: T1-1 Payload Loopback Incoming PCM from span B is sent to the input of LIU B, then from the output of LIU B to the input of LIU A, and finally from the output of LIU A to the output of span A.
Page 209 Chapter 5. Diagnostics Drop-and-Insert: T1-2 Payload Loopback Incoming PCM from span A is sent to the input of LIU A, then from the output of LIU A to the input of LIU B, and finally from the output of LIU B to the output of span B. PCM from the output of LIU A is also sent to the output of span A.
Page 210: Dual Channel Bank: Normal Operation
Chapter 5. Diagnostics Dual Channel Bank: Normal Operation In Dual Channel Bank operation, the D/I Mux III acts as two separate channel banks, one looking to T1-1, and the other looking to T1-2. The Dual CSU Interface routes incoming PCM from span B to the input of LIU B, and sends PCM from the output of LIU B to the output of span B.
Page 211: Dual Channel Bank: Line Loopback
Chapter 5. Diagnostics Dual Channel Bank: Line Loopback Line loopback is set in response to receiving a Line Loop Set code on a span's input. PCM arriving at the input is looped back to the opposite span's output. The LIUs are not in the PCM path.
Page 212 Chapter 5. Diagnostics Dual Channel Bank: T1-2 Line Loopback Line Loop Set code received on the input of span A causes PCM to be looped back out the output of span B. Output PCM from LIU A is sent to the output of span A. PCM from the input of span B and the output of LIU B are blocked.
Page 213 Chapter 5. Diagnostics Dual Channel Bank: T1-1 and T1-2 Line Loopback Line Loop Set code received on span B input causes PCM to be looped back out span A's output before reaching the LIUs, as well as being passed on to the input of LIU B. The PCM from the output of LIU B is blocked.
Page 214: Dual Channel Bank: Payload Loopback
Chapter 5. Diagnostics Dual Channel Bank: Payload Loopback Payload loopback is initiated from the D/I Mux III software interface. In payload loopback, the LIUs are included in the data path; line loopback does not include the LIUs. In payload loopback, the loopback occurs after rather than before the LIUs.
Page 215 Chapter 5. Diagnostics Dual Channel Bank: T1-2 Payload Loopback PCM from span A (T1-2) is sent to the input of LIU A. The output of LIU A is looped to the input of LIU B. The output of LIU B is sent out on span B (T1-2). The input from span B (T1-1) is blocked, as is the output path to span A (T1-1).
Page 216: Software Diagnostics
Chapter 5. Diagnostics Software Diagnostics The following section illustrates and describes the various screens and processes for performing software diagnostics on the D/I Mux III system. Examples are included for diagnostics and performance monitoring. OL - Operate Line Card Diagnostics Enter OL to display the Operate Line card diagnostics screen on a specific line card, as depicted in Figure 5-24.
Page 217: Od - Operate Diagnostics
Chapter 5. Diagnostics OD - Operate Diagnostics Enter OD to access the Operate Diagnostics screen as depicted below. The example in Figure 5-25 is of a Dual CSU Interface (Integrated CSU) card in channel bank mode. ] OD 17:19:37----------- [ Operate Diagnostics ] ----------02/01/96 CSU Loopback Normal T1-1...
Page 218 Chapter 5. Diagnostics Figure 5-26 displays diagnostics options in drop-and-insert and dual channel bank modes, with a Dual CSU Interface. Choose the desired T1 port loopback as listed under the T1-1 or T1-2 column. ] OD 17:22:12 --------- [ Operate Diagnostics ] ---------- 02/01/96 CSU Loopback Normal T1-1...
Page 219 Chapter 5. Diagnostics When using a Dual DSX-1 Interface the available diagnostics options are limited to the selections shown in Figure 5-27. ] OD 17:24:18---------- [ Operate Diagnostics ]-------- 06/25/96 T1 Interface Normal Shelf Controls -------------- C) Bypass E) Reset Common/Line Cards D) Unbypass F) Unloop Line Cards G) Shelf Restart...
Page 220: Performance
Chapter 5. Diagnostics Performance Enter PM to begin the Performance Monitoring sequence. This screen will only appear if a Facilities Data Link Processor (FDLP) is installed in the multiplexer. Consult the FDLP User’s Manual for the various options of the Performance Monitor screen, as depicted in Figure 5-28. ] PM 10:40:23---------- [ PERFORMANCE MONITOR ]----------- 03/08/96 Select Direction...
Page 221: Sb - Set Bit Error Rate Options
This requires spares on hand, or a call to Coastcom to expedite a replacement unit. Before a replacement unit is shipped, it must be confirmed as a failure by a Coastcom Technical Support Engineer. Call Technical...
Page 222: D/I Mux Iii Messages
Chapter 5. Diagnostics D/I Mux III Messages Table 5-4 lists all of the D/I Mux III error and status messages. Messages appear within the table in alphabetical order. Table 5-4. D/I Mux III Messages (Page 1 of 3) Error Message Cause Solution Card Removed...
Page 223 Chapter 5. Diagnostics Error Cause Solution Message Invalid Slot Range Slot range entered was not a number Check the range, then enter the (1-N) between 1 and 8 for the 8-slot shelf; or not numbers again. (To check for proper a number between 1 and 12 for the 12-slot shelf size, use the SP command.) shelf;...
Page 224 Chapter 5. Diagnostics Error Cause Solution Message Reinstall Line Power-up sequence of the line card is not Install line card again, perhaps with power off. Card Error correct. Switch to Normal Self explanatory. Informational message only; no action required. Mode That Slot Appears Operation cannot be performed because Check to see if a card is in the slot.
Page 225: Alarm Reporting
Chapter 5. Diagnostics Alarm Reporting Table 5-5 describes the various D/I Mux III alarms. Each is grouped as Major, Minor, or Info as applicable. Table 5-5. Alarm Reporting (Page 1 of 2) Alarm Severity Report Log into Description to NCC History Card Major...
Page 226 Chapter 5. Diagnostics Alarm Severity Report Log into Description to NCC History Prov Bus Err Info Tx and/or Rx failed over the provisioning bus. Diagnostics Info Card diagnostics failed. LINE T1-1 Info The T1-1 span is looped back towards the network. Message at LPBK the looped end.
Page 227 D/I Mux III User’s Manual Appendix A. D/I Mux III Specifications APPENDIX A. D/I MUX III SPECIFICATIONS...
Page 228: Appendix A. D/I Mux Iii Specifications
D/I Mux III User’s Manual Appendix A. D/I Mux III Specifications Appendix A. D/I MUX III SPECIFICATIONS The following tables list the various D/I Mux III system specifications. DS1 Signal 2 x 1.544 Mbps ± 200 bps Line Rate Format...
Page 229 D/I Mux III User’s Manual Appendix A. D/I Mux III Specifications Configuration and Control Software Controlled With use of an ASCII terminal, Telnet, SNMP User Test Functions Test Loopback Loops towards user’s equipment to test CSU and user’s equipment (software control) Network Loopback Transmits and receives network loop codes with software or front panel switches...
Page 230 D/I Mux III User’s Manual Appendix A. D/I Mux III Specifications Data Line Cards SDM - Subrate Data Multiplexer SDM: 1.2 - 19.2 Kbps; 5-Port DS0B, Sync/Async 1-Port DS0A, Sync/Async pSDM: Point-to-Point & Multipoint; 0 - 19.2 Kbps Async MSDM: Multipoint; 12 - 19.2 Kbps; 5-Port Async, RS-232 SDCU - Synchronous Data 56/64 Kbps;...
Page 231 D/I Mux III User’s Manual Appendix A. D/I Mux III Specifications Dimensions and Weight 8-Slot 12-Slot 24-Slot Shipping Weight (fully equipped) 17 Pounds 31 Pounds 45 Pounds Width 17.00 Inches 17.00 Inches 17.00 Inches Depth 11.75 Inches 11.75 Inches 11.75 Inches Height 5.25 Inches 7.00 Inches...
Page 232 D/I Mux III User’s Manual Appendix B. –24 Volt Systems APPENDIX B. -24 VOLT SYSTEMS...
Page 233: Appendix B. -24 Volt Systems
(650 ohm maximum) has a limited distance range when used in -24 V systems. Allow for one-half the cabling distance. 30058-001 C1SDCU - The C1DCU Control Unit will work in a –24 V system. However, a +24 V system will require an isolated ground. Coastcom does not provide an isolated ground.
Page 234 D/I Mux III User’s Manual Appendix C. Accessories Installation APPENDIX C. ACCESSORIES INSTALLATION...
Page 235: Appendix C. - Accessories Installation
Appendix C. Accessories Installation Appendix C. - ACCESSORIES INSTALLATION Coastcom provides various accessories that can be used with D/I Mux III multiplexers for troubleshooting and maintenance purposes as well as for special applications. The following sections list and describe these optional accessories, and include procedures for their installation.
Page 236: Ringing Generator
D/I Mux III User’s Manual Appendix C. Accessories Installation Ringing Generator The Ringing Generator (P/N 30034-003) is used to supply ringing voltage for applications with more than 20 Megacom, or heavily used FXS circuits. An external Ringing Generator used with FXS circuits may require -48 V DC.
Page 237 D/I Mux III User’s Manual Appendix D. Preconfigured Maps APPENDIX D. PRECONFIGURED MAPS...
Page 238: Appendix D. Preconfigured Maps
D/I Mux III User’s Manual Appendix D. Preconfigured Maps Appendix D. PRECONFIGURED MAPS Eight pre-configured maps are available on the Strobe unit, and are described in this appendix. Select a map to match the desired application from the maps described in this appendix. If a map is required which differs from those supplied here, use the Set/edit Map matrix (SM) command to configure a custom map.
Page 239: Strobe Option Switch #1 - 24-Card Slots: 64 Kbps Per Slot
D/I Mux III User’s Manual Appendix D. Preconfigured Maps Following are the eight preconfigured maps available through use of the strobe switches. Strobe Option Switch #1 - 24-Card Slots: 64 Kbps per Slot Rows represent card slots and columns represent timeslots. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24...
Page 240: Strobe Option Switch #2 - 12-Card Slots: Two 64 Kbps Per Slot
D/I Mux III User’s Manual Appendix D. Preconfigured Maps Strobe Option Switch #2 - 12-Card Slots: Two 64 Kbps per Slot Rows represent card slots and columns represent timeslots. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 10 A 10 B 11 A...
Page 241: Strobe Option Switch #3 - 12-Card Slots: 128 Kbps Per Slot
D/I Mux III User’s Manual Appendix D. Preconfigured Maps Strobe Option Switch #3 - 12-Card Slots: 128 Kbps per Slot Rows represent card slots and columns represent timeslots. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 TR TR TR TR TR TR...
Page 242: Strobe Option Switch #5 - 6-Card Slots: 256 Kbps Per Slot
D/I Mux III User’s Manual Appendix D. Preconfigured Maps Strobe Option Switch #5 - 6-Card Slots: 256 Kbps per Slot Rows represent card slots and columns represent timeslots. 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 16 17 18 19 20 21 22 23 24 TR TR TR TR TR TR TR TR TR TR TR TR...
Page 243 D/I Mux III User’s Manual Appendix E. SNMP APPENDIX E. SNMP...
Page 244: Appendix E. Snmp
Ethernet 10Base-T, or token ring, using the TCP/IP protocol stack, or communication interface. Coastcom’s Advanced Multiplexer Control Units (AMCUs) use only the 10Base-T protocol. SNMP allows both the SNMP manager and the managed device (the agent) to send packets to multiple destinations without first negotiating a connection through use of User Datagram Protocol (UDP) over IP.
Page 245 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects APPENDIX F. MIB II AND DS1 MIB GROUP NAMES AND OBJECTS...
Page 246: Appendix F. Mib Ii And Ds1 Mib Group Names And Objects
D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Appendix F. MIB II AND DS1 MIB GROUP NAMES AND OBJECTS Managed objects are accessed via a virtual information store, called the Management Information Base, or MIB.
Page 247 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II (RFC 1213) Groups and Objects Group/Object Name Description System Group sysDescr A textual description of the entity. sysObjectID The vendor's authoritative identification of the network management subsystem contained in the entity.
Page 248 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description The current operational state of the interface. ifOperStatus ifLastChange The value of sysUpTime at the time the interface entered its current operational state.
Page 249 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) IP Group Group/Object Name Description ipForwarding The indication of whether this entity is acting as an IP gateway for the forwarding of datagrams received by, but not addressed to, this entity.
Page 250 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description ipReasmTimeout The maximum number of seconds which received fragments are held while they are awaiting reassembly at this entity.
Page 251 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description ipRouteIfIndex The index value that uniquely identifies the local interface through which the next hop of this route should be reached.
Page 252 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description ICMP Group icmpInMsgs The total number of ICMP messages which the entity received. icmpInErrors The number of ICMP messages which the entity received but determined as having ICMP-specific errors (bad ICMP checksums, bad length, etc.).
Page 253 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description icmpOutSrcQuenchs The number of ICMP Source Quench messages sent. The number of ICMP Redirect messages sent. icmpOutRedirects The number of ICMP Echo (request) messages icmpOutEchos...
Page 254 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description tcpEstabResets The number of times TCP connections have made a direct transition to the CLOSED state from either the ESTABLISHED or the CLOSE- WAIT state.
Page 255 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description udpOutDatagrams The total number of UDP datagrams sent from this entity. udpTable A table containing UDP listener information. udpEntry Information about a particular current UDP listener.
Page 256 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description snmpInGenErrs The total number of SNMP PDUs delivered to the SNMP protocol entity, and for which the value of the error-status field is ‘genErr’.
Page 257 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-1. MIB-II Groups and Objects (Continued) Group/Object Name Description snmpOutSetRequests The total number of SNMP Set-Request PDUs generated by the SNMP protocol entity. snmpOutGetResponses Total number of SNMP Get-Response PDUs generated by the SNMP protocol entity.
Page 258 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-2. DS1 MIB (RFC 1406) Groups and Objects Group/Object Description DS1 Near End Group The DS1 Configuration table. dsx1ConfigTable An entry in the DS1 Configuration table. dsx1ConfigEntry This object is the identifier of a DS1 Interface on a dsx1LineIndex...
Page 259 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-2. DS1 MIB (RFC 1406) Groups and Objects Group/Object Description The index value which uniquely identifies the dsx1CurrentIndex DS1 interface to which this entry is applicable. The number of Errored Seconds encountered dsx1CurrentESs by a DS1 interface in the current 15-minute...
Page 260 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-2. DS1 MIB (RFC 1406) Groups and Objects Group/Object Description dsx1IntervalESs The number of Errored Seconds encountered by a DS1 interface in one of the previous 96 individual 15-minute intervals.
Page 261 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-2. DS1 MIB (RFC 1406) Groups and Objects Group/Object Description The number of Severely Errored Framing dsx1TotalSEFSs Seconds encountered by a DS1 interface in the previous 24-hour interval.
Page 262 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-2. DS1 MIB (RFC 1406) Groups and Objects Group/Object Description The number of Unavailable Seconds dsx1FarEndCurrentUASs encountered by a DS1 interface in the current 15-minute interval.
Page 263 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-2. DS1 MIB (RFC 1406) Groups and Objects Group/Object Description The number of Unavailable Seconds dsx1FarEndIntervalUASs encountered by a DS1 interface in one of the previous 96 individual 15-minute intervals.
Page 264 D/I Mux III User’s Manual Appendix F. MIB II and DS1 MIB Group Names and Objects Table F-2. DS1 MIB (RFC 1406) Groups and Objects Group/Object Description The number of Far End Line Errored Seconds dsx1FarEndTotalLESs encountered by a DS1 interface in the previous 24-hour interval.
Page 265 D/I Mux III User’s Manual Appendix G. Modem Interfaces APPENDIX G. MODEM INTERFACES...
Page 266: Appendix G. Modem Interfaces
The receiving end demodulates the carrier, and converts the analog representation of the data back to digital form for the receiving computer. Coastcom uses modems that are compatible with the Hayes Command Set for modems.
Page 267: D/I Mux Iii Characters
DXC II Characters The firmware in Coastcom’s DXC II system also allows modem control strings to be configured as desired with special characters, except that the DXC II does not insert BREAK signals.
Page 268 D/I Mux III User’s Manual Appendix G. Modem Interfaces Table I-2 lists and describes the Hayes Smartmodem 300 commands. Table H-2. Hayes Smartmodem 300 Command Set Command Description Attention prefix; precedes all commands, except escape sequence and the repeat command (A/). Repeat last command.
Page 269 D/I Mux III User’s Manual Appendix G. Modem Interfaces Table H-2. Hayes Smartmodem 300 Command Set (Continued) Command Description Go on hook (hang up). Line and auxiliary relays off hook. Line relay only off hook. The Hayes Smartmodem contains an additional relay that can be used to control equipment, independent of the telephone line relay.
Page 270: Hayes 1200 And 1200B Command Sets
D/I Mux III User’s Manual Appendix G. Modem Interfaces Hayes 1200 and 1200B Command Sets The Smartmodem 1200/1200B commands and dial modifiers are super sets of the Smartmodem 300 commands. They are listed and described in Table I-3. Table H-3. Hayes 1200 and 1200B Command Sets Command Feature Select CCITT V.22 as communications standard.
Page 271: Smartmodem 2400/2400B Command Set
D/I Mux III User’s Manual Appendix G. Modem Interfaces Smartmodem 2400/2400B Command Set The Smartmodem 2400 and the Smartmodem 2400B command sets are super sets of the Smartmodem 1200 command set with some exceptions, and are listed and described in Table I-4. The following commands are no longer available: •...
Page 272 D/I Mux III User’s Manual Appendix G. Modem Interfaces Table H-4. Smartmodem 2400/2400B Command Set (Continued) The following commands are used with newer model 2400 bps modems. Command Description Assume data carrier always present (DCD signal). &C0 Track presence of data carrier. &C1 This command (found on a large number of clones) causes the most problems when moving to a 2400 bps modem from a slower speed.
Page 273 D/I Mux III User’s Manual Appendix G. Modem Interfaces Table H-4. Smartmodem 2400/2400B Command Set (Continued) Command Description &R0 Track CTS according to RTS. Ignore RTS; always assume presence of CTS. &R1 In the default state (&RI), CTS is forced on. In &R1, CTS follows RTS with the value specified in register S26.
Page 274: V-Series Commands
D/I Mux III User’s Manual Appendix G. Modem Interfaces V-Series Commands Additional commands were introduced with the Hayes V-series modems. They are listed and described in Table I-5. Table H-5. V-Series Modem Commands Command Description Speed control. Result code control. Negotiation result control.
Page 275 D/I Mux III User’s Manual Appendix G. Modem Interfaces Table I-6 lists and describes the result codes, with associated control, included with the V-series Xn commands (refer to Table I-5 above). Table H-6. Result Codes Based On Xn Commands Commands Code Verbose CONNECT...
Page 276 D/I Mux III User’s Manual Appendix G. Modem Interfaces The Smartmodems also include S-Registers, permitting selection of rings before answering. Table I-7 lists and describes the S-Register options. Table H-7. Smartmodem S-Registers S- Register Description Auto-answer mode where n = the number of S0=n rings before the modem answers, OR 0 = do not answer.
Page 277: Modem Considerations
D/I Mux III User’s Manual Appendix G. Modem Interfaces Modem Considerations There are a number of considerations to be taken into account when planning modem installation. Among the problems that might be encountered are line noise, timing discrepancies, sequencing difficulty, and control signalling errors. Each is described below. Line Noise Noise on the telephone line can inject data errors, can cause loss of carrier, and can and terminate the connection.
Page 278: Modems And The Ncc System
The basic sequence for modem call processing is listed below. More specific steps are listed in the following section for connecting and terminating modems when using the D/I Mux III system, the Digital Cross Connect II (DXC II) system, and the Network Communications Controller (NCC) system.
Page 279: Processing Messages
Processing Messages Proceed with message transmissions. Alarm mode switching during message processing is controlled by Coastcom’s NCC5 and NCC6 programs when communicating with the D/I Mux III system (the NCC2 program does not switch alarm modes). The program sends a Machine Machine Language (MML) command to disable alarm reporting, thus allowing ASCII or MML data transmission/reception to occur.
Page 280: Terminating Connection
D/I Mux III User’s Manual Appendix G. Modem Interfaces Terminating Connection At the conclusion of transmission, the connection must be terminated. Follow the steps listed below for terminating connection with each device listed. Port Expander If a port expander, or other black box device, has been configured into the network follow the steps listed below, otherwise proceed to the next section.
Page 281: Modems And D/I Mux Iii Or Dxc Ii Systems
Wait for an OK response (which should appear within 3 seconds), and continue. Port Coastcom’s NCC5 program will release the serial port back to the system. The NCC2 and NCC6 programs will release the port by restoring the original serial interrupt vector.
Page 282: Connection Stabilization
Processing Messages Proceed with message transmissions. Alarm mode switching during message processing is controlled by Coastcom’s NCC5 and NCC6 programs when communicating with the D/I Mux III system (the NCC2 program does not switch alarm modes). The program sends a Machine Machine Language (MML) command to disable alarm reporting, thus allowing ASCII or MML data transmission/reception to occur.
Page 283 D/I Mux III User’s Manual Appendix G. Modem Interfaces Send the hang-up command, using the following command string: ATH! Wait for an OK response (should appear within 3 seconds), and continue. Send the initialization command to the modem using the following recommended command string: AT E0 Q1 S0=1 V1 X4 &C0 &D0! Wait for an OK response (should appear within 3 seconds), and continue.
Page 284 D/I Mux III User’s Manual Appendix H. Set Report Options APPENDIX H. SET REPORT OPTIONS...
Page 285: Appendix H. Set Report Options
The options include the following. • COMM mode: Selects the desired communications mode; options are either basic terminal control, or Machine Machine Language (MML) control when Coastcom’s Network Communications Controller (NCC) software product is used. •...
Page 286: Setting Communications In Terminal Mode With Inaudible Terminal Alarm Reporting
D/I Mux III User’s Manual Appendix H. Set Report Options Setting Communications in Terminal Mode With Inaudible Terminal Alarm Reporting Figure J-1 depicts the Set report Options (SO) command sequence screen, resulting in communications in terminal mode with inaudible terminal alarm reporting. Selecting option C under Communication Configuration sets the communications mode.
Page 287 D/I Mux III User’s Manual Appendix H. Set Report Options Current Mode TERM - NO ALARM REPORTING Communication Configuration C) COMM mode D) Display Modem/Port expander conf. M) Change Modem Conf. P) Change Port Expander Conf. Q) Quit C COMM mode: T) Terminal M) MML [TERM] T...
Page 288: Setting Communications In Terminal Mode With Modem Dial-Out
D/I Mux III User’s Manual Appendix H. Set Report Options Setting Communications in Terminal Mode With Modem Dial-Out Figure J-2 depicts the Set report Options (SO) command sequence screen, resulting in communications in terminal mode with modem dial-out enabled. Selecting option C under Communication Configuration sets the communications mode. Then, selecting option T specifies that communications will be controlled by a terminal versus MML.
Page 289 D/I Mux III User’s Manual Appendix H. Set Report Options Current Mode TERM - NO ALARM REPORTING Communication Configuration C) COMM mode D) Display Modem/Port expander conf. M) Change Modem Conf. P) Change Port Expander Conf. Q) Quit C COMM mode: T) Terminal M) MML [TERM] T...
Page 290: Setting Communications In Terminal Mode With Alarm Reporting Off
D/I Mux III User’s Manual Appendix H. Set Report Options Setting Communications in Terminal Mode With Alarm Reporting Off Figure J-3 depicts the Set report Options (SO) command sequence screen, resulting in communications in terminal mode with alarm reporting turned off. Selecting option C under Communication Configuration sets the communications mode.
Page 291 D/I Mux III User’s Manual Appendix H. Set Report Options Current Mode TERM - NO ALARM REPORTING Communication Configuration C) COMM mode D) Display Modem/Port expander conf. M) Change Modem Conf. P) Change Port Expander Conf. Q) Quit C COMM mode: T) Terminal M) MML [TERM] T...
Page 292: Setting Communications In Mml Mode With Modem Dial-Out Enabled
Machine Machine Language (MML) mode with alarm reporting modem dial-out enabled. MML is the language used by Coastcom’s Network Communications Controller (NCC) software product. If still connected to a terminal when entering this option, extra characters will appear on the terminal screen.
Page 293 D/I Mux III User’s Manual Appendix H. Set Report Options Current Mode TERM - NO ALARM REPORTING Communication Configuration C) COMM mode D) Display Modem/Port expander conf. M) Change Modem Conf. P) Change Port Expander Conf. Q) Quit C COMM mode: T) Terminal M) MML [TERM] m...
Page 294: Setting Communications In Mml Mode With Modem Dial-Out Disabled
Machine Machine Language (MML) mode with alarm reporting modem dial-out disabled. MML is the language used by Coastcom’s Network Communications Controller (NCC) software product. If still connected to a terminal when entering this option, extra characters will appear on the terminal screen.
Page 295 D/I Mux III User’s Manual Appendix H. Set Report Options Current Mode TERM - NO ALARM REPORTING Communication Configuration C) COMM mode D) Display Modem/Port expander conf. M) Change Modem Conf. P) Change Port Expander Conf. Q) Quit C COMM mode: T) Terminal M) MML [TERM] m...
Page 296: Displaying Modem And Port Expander Information
D/I Mux III User’s Manual Appendix H. Set Report Options Displaying Modem and Port Expander Information Figure J-7 depicts the Set report Options (SO) command sequence screen, permitting selection of the D) Display Modem/Port Expander Configuration option. Current Mode TERM - NO ALARM REPORTING Communication Configuration C) COMM mode D) Display Modem/Port expander conf.
Page 297: Feature Group 6.0/6.2 Screen Changes
D/I Mux III User’s Manual Appendix H. Set Report Options The Display Modem and Port Expander Configuration screen appears, listing all current alarm dial-out configuration data. Figure J-8 depicts a modem and port expander configuration screen. 16:49:16 -------------[ Alarm Dial Out ]------------- 07/09/92 Interval Between Calls : 3 mins Last Message Time Out : 20 secs Port Expander Present...
Page 298: Configuring The Modem
The next four entries call for the Attention String, the Dial String, the Modem Hang-up String, and the Modem Initiation String. In each case, the default string command appears in the prompt brackets. Coastcom recommends use of these default commands. Figure J-9 on the following page depicts the modem configuration sequence as described here.
Page 299 D/I Mux III User’s Manual Appendix H. Set Report Options Communication Configuration C) COMM mode D) Display Modem/Port expander conf. M) Change Modem Conf. P) Change Port Expander Conf. Q) Quit m Intervals Between Call Attempts In Minutes (3..127) Last Message Time Out In Seconds (3..127) [20] Do You Have A Modem...
Page 300: Displaying New Modem Configuration
D/I Mux III User’s Manual Appendix H. Set Report Options Displaying New Modem Configuration After all modem configuration options are selected, the Alarm Dial Out screen displays automatically. Each of the options set during configuration are reflected on the terminal screen, with the Apply Changes “save”...
Page 301: Configuring The Port Expander
Port Expander Link Response, the Port Expander Unlink String, and the Port Expander Unlink Response String. In each case, the default string command appears in the prompt brackets. Coastcom recommends use of these default commands. Figure J-11, on the following page, depicts the port expander configuration options screen.
Page 302 D/I Mux III User’s Manual Appendix H. Set Report Options Communication Configuration C) COMM mode D) Display Modem/Port expander conf. M) Change Modem Conf. P) Change Port Expander Conf. Q) Quit p Do You Have A Port Expander Y) Yes N) No [N] y NCC Port...
Page 303: Displaying New Port Expander Configuration
D/I Mux III User’s Manual Appendix H. Set Report Options Displaying New Port Expander Configuration After all port expander configuration options are selected, the Alarm Dial Out screen displays automatically. Each of the options set during configuration are reflected on the terminal screen, with the Apply Changes “save”...
Page 304: Quitting Alarm Reporting Configuration
D/I Mux III User’s Manual Appendix H. Set Report Options Quitting Alarm Reporting Configuration After saving all configuration settings, the screen prompts to “Press Enter to Continue”, after which the Communication Configuration menu will again display. The option to Quit is available whenever this menu displays.
Page 305 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration APPENDIX I. TRAPS AND MODEM DIAL OUT CONFIGURATION...
Page 306: Appendix I. Traps And Modem Dial Out Configuration
D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration Appendix I. Traps and Modem Dial Out Configuration AMCU New Screens Three new commands are now available on the AMCU. Two commands (Modify Dial Out Parameters, and View Dial Out parameters) are for viewing and/or modifying the Modem Dialout Parameters.
Page 307 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration TRAPS The normal communication path in an SNMP system is from the manager(s) to a specific node (the agent). Usually the manager initiates communication by sending a request (set, get, get-next) and the agent (AMCU) responds.
Page 308 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration Modify T1 Alarm Trap Conditions ------------------------------- 1 Modify T1 line one criteria Q Quit Select: [Q] 15:43:37 --------[ Set T1 Line Trap Criteria - T1 One ]-------- 06/19/97 If any alarm marked Check is present, the T1 line will be considered down.
Page 309 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration SELECT TRAP CRITERIA By selecting option 8 the AMCU is now told that if a CGA (Carrier Group Alarm) occurs to send a linkDown Trap to the SNMP Manager. 15:43:53 --------[ Set T1 Line Trap Criteria - T1 One ]-------- 06/19/97 If any alarm marked Check is present, the T1 line will be considered down.
Page 310 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration EXIT MODIFY ALARM TRAP The site operator has now set the criteria which the AMCU will use in determining if a link has failed and will end this session with “Q”. The operator then chooses to keep the changes and exit with “D”. Modify T1 Alarm Trap Conditions ------------------------------- 1 Modify T1 line one criteria...
Page 311 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration The path for this system is: D/I Mux III with an AMCU, to an external modem (using a cable with an RJ-45 connector on the AMCU end and a DB-9 connector on the modem end) to a phone line to the Network, from the network to a modem to the SNMP manager Mux.
Page 312 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration MODIFY DIAL OUT After inputting the “MD” command, the first menu selection lets the user tell the system whether or not to configure the SLIP port for a modem Modify Dial Out Parameters ------------------------------- M Modem present?
Page 313 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration SET TIMEOUT Selecting menu option “T” the user sets the number of inactive minutes allowed before the modem hangs up. Minimum is approximately 15-20 seconds but is rounded to zero minutes. Sending or receiving a SLIP packet restarts the timer.
Page 314 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration INPUT MODEM INITIALIZATION STRING Menu option I allows the user to input a modem initialization string Modify Dial Out Parameters ------------------------------- M Modem present? T Timeout I Modem initialization string N Dail out numbers V View dial out parameters Q Quit...
Page 315 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration ANALYSIS OF DEFAULT INITIALIZATION STRING Note: This is a breakdown analysis of the default initialization string. ATZV1&D2&C1E0 AT is the attention prefix—this precedes all commands except for escape sequence or the repeat command.
Page 316 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration INPUT DIAL OUT NUMBERS The N option of the menu allows the user to input the numbers the modem will use to dial out to. The “atdt” string is a command string for the modem to go into dial out mode ( any command to a Hays or Hays comparable modem must start with “at”...
Page 317 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration ADD A NUMBER After choosing the N option the user selects a from the sub menu to add a number to the dial out list. . Edit Dial Out Numbers A Add a number C Change a number D Delete a number...
Page 318 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration INSERT OR ADD A NUMBER Now the operator can choose where in the list to put the new number. Add a new dial out number: B Insert at the beginning of the list. 1 Add a new number after number #1.
Page 319 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration Up to 5 numbers can be listed. The modem will begin the dial out sequence with the first number in the list. If the first number is busy, the modem will automatically dial out the next number in the list. The modem will cease dialing after it has tried and not connected with all 5 numbers.
Page 320 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration SELECT NUMBER TO CHANGE This sub menu then asks the operator which number he wishes to change. Change a dial out number: 1 Change number #1. 2 Change number #2. Q Quit Please enter one of 1 through 2, or Q [Q] Please enter a new value (zero to 32 characters).
Page 321 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration DELETE A NUMBER If, for some reason, a dial out number is no longer of any use it can be deleted by the D command. Edit Dial Out Numbers Add a number Change a number Delete a number...
Page 322 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration CHOOSE THE NUMBER TO DELETE This sub menu allows the operator chooses which number to delete. Delete a dial out number: Delete number #1. Delete number #2. Quit Please enter one of 1 through 2, or Q [Q] Dial Out Number Command Strings...
Page 323 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration VIEW PARAMETERS The V command allows the user to view the modem parameters he has set. Modify Dial Out Parameters ------------------------------- M Modem present? T Timeout I Modem initialization string N Dail out numbers V View dial out parameters Q Quit...
Page 324 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration QUIT MODEM DIAL OUT All of the changes need have been made and now the user can exit the configuration program with the Q command. Modify Dial Out Parameters ------------------------------- M Modem present? T Timeout...
Page 325 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration VD View Dial Out Parameters This command allows the operator to view the current configuration, or a new configuration after a session with the MD command. 15:43:11 ----------------[ Dialer Parameters ]----------------- 06/19/97 Modem Connected to SLIP port: Yes Modem Inactivity Timeout: 1 Min.
Page 326 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration MODEM CABLE PINOUTS The table and diagram below show the pinouts for the cable that connects the AMCU with the modem. The Modem end of the cable is a dB-9 connector, while the AMCU end is an RJ-45 connector (again this is for a Hays modem, if the DB connector on your modem is different please consult your modem manual)..
Page 327 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration Figure J-20 RJ-48 pin out...
Page 328 D/I Mux III User’s Manual Appendix I. Traps and Modem Dial Out Configuration Note: The two levels of passwords (AMCU and CCU) have been eliminated. One password is used (level 1, 2, or 3) in logging on. This affects access to commands on the AMCU and CCU screens appropriately, i.e., according to the status level when logging on.
Page 329: Hardware Warranty And 90-Day Support Agreement
Coastcom representative. Shipping costs, if any, incurred in connection with the return of a defective item to Coastcom will be paid by Customer. Any shipping costs incurred in connection with the return of a repaired or replaced item shall be the responsibility of Coastcom. However, such costs shall be the responsibility of the Customer if Coastcom determines that the item is NOT defective.

Coastcom D/I Mux III System User Manual

Chapter 1. System Overview and Modes of Operation

Component Overview

Modes of Operation

Chapter 2. Applications

Chapter 3. Installation

Chapter 4. Configuration and Operation

Chapter 5. Diagnostics

Appendix A. D/I Mux III Specifications

Appendix B. -24 Volt Systems

Appendix C. - Accessories Installation

Appendix D. Preconfigured Maps

Appendix E. Snmp

Appendix F. Mib II and Ds1 Mib Group Names and Objects

Appendix G. Modem Interfaces

Appendix H. Set Report Options

Appendix I. Traps and Modem Dial out Configuration

Hardware Warranty and 90-Day Support Agreement

Quick Links

Troubleshooting

Need help?

Questions and answers

Summary of Contents for Coastcom D/I Mux III System
