The set point is the value (the mantissa) raised to the specified power (exponent) at which alarms are
generated. To change the ERT set point or threshold, enter 1 as shown in Figure 4-42.
T1-1 Alarm Set Pt.
Mantissa (1..9)
[9]
Exponent (3..6)
[3]
The resolution determines the size of the T1 signal sample. The higher the resolution, the longer it takes
to complete sampling. To change the ERT resolution, enter a selection option as shown in Figure 4-43.
T1-1
Min. Resolution
1) 1E-5
2) 1E-6
3) 1E-7
4) 1E-8
[2]
Chapter 4. Configuration and Operation
Figure 4-42. Setting Set Points
Sample Time
12.5 Secs
2 Mins
21 Mins
3.5 Hrs
Figure 4-43. Setting ERT Resolution
