Coastcom D/I Mux III System User Manual page 136

DL - Displaying Line Card Table
Enter DL to Display the installed Line card table (Figure 4-14). Smart and non-intelligent cards specified
through use of the Set Line card configuration (SL) command, are displayed. Active data rates are
shown for all mapped cards.
] DL
Slot RANGE
*) All Slots
[1-12]
10:15:46---------------- [ Line Card Table ]----------------- 03/08/95
Slot Label Card Type
----------------------------------------------------------------------
3 A D4W
3 B D4W
5 SDM
7 OCUDP
----------------------------------------------------------------------
Chapter 4. Configuration and Operation
Power Up Data Rate
Config. ( T
Switch 0K
Switch 0K
NV Ram 64K
Switch 56K
Figure 4-14. Displaying Installed Line Card Table
R ) # of DS0s
0K 1
0K 0
64K 1
56K 1
116
Direction
T1-1
T1-1
T1-1
