Coastcom D/I Mux III System User Manual page 223

Error
Message
Invalid Slot Range Slot range entered was not a number
(1-N) between 1 and 8 for the 8-slot shelf; or not
a number between 1 and 12 for the 12-slot
shelf; or not a number between 1 and 24
for the 24-slot shelf; or the first number of
the range was greater than the second
number.
LIU B Slot is Self explanatory.
Empty
LIU A Slot is Self explanatory.
Empty
Lower Strobe Card Self explanatory.
Not Installed
Lower Strobe Self explanatory.
Error
Map is Working This map is the working map and its
status cannot be modified or changed
while it is the working map.
Map Not Enabled A disabled map cannot be made the
working map.
Original Alarm Only one alarm map can be enabled at a
Map Working time. Another alarm map is already
enabled and its status cannot be changed
because it is currently the working map.
Normally, when a second alarm map is
enabled, the first alarm map is disabled,
unless it is the working map.
Original Event Only one event map can be enabled at a
Map Working time. Another event map is already
enabled and its status cannot be changed
because it is currently the working map.
Normally, when a second event map is
enabled, the first event map is disabled,
unless it is the working map.
Original Time Map Only one time map can be enabled at a
Working time. Another time map is already
enabled and its status cannot be changed
because it is currently the working map.
Normally, when a second time map is
enabled, the first time map is disabled,
unless it is the working map.
Password Already Duplicate passwords are not allowed.
Used
Password Table A maximum of eight passwords are
Full allowed, and eight are already entered.
Request is Not Self explanatory.
Allowed
Chapter 5. Diagnostics
Cause
203
Solution
Check the range, then enter the
numbers again. (To check for proper
shelf size, use the SP command.)
Informational message only; no action
required.
Informational message only; no action
required.
Informational message only; no action
required.
Check the lower strobe card and retry
operation.
Make another map the working map
(copy the working map), or choose
another map to modify.
Change the status of the map to
Enabled before making it the working
map.
Change the first alarm map so that it is
not the working map. Then try again to
change the status of the second alarm
map to Enabled.
Change the first event map so that it is
not the working map. Then try again to
change the status of the second event
map to Enabled.
Change the first time map so that it is
not the working map. Then try again to
change the status of the second time
map to Enabled.
Select and enter another password.
Delete an already-defined password,
then enter the new password.
Make corrections and retry. If
appropriate, respond to system prompts
to correct the problem.
