Appendix A. D/I MUX III SPECIFICATIONS

The following tables list the various D/I Mux III system specifications.
Line Rate
Line Code
Zero Suppression Mode
Clear Channel
Transmit Signal
Receive Signal
Input/Output Impedance
T1 Connections
Transmit Equalization (DSX)
Transmit Line Build-Out (CSU)
Network Compatibility
Maximum Bandwidth
8, 12, or 24 Data Ports
Access (Bantam)
Monitor (Bantam)
Format
Framing
Number
Type
Number
Type
Dual CSU Interface (Integrated CSU) Jacks
DS1 Signal
2 x 1.544 Mbps ± 200 bps
D4 Mode 3, or ESF
24 DS0 64 Kbps channels; 8 Kbps framing overhead
(per AT&T Pub 62411)
AMI
B7, B8ZS, or Transparent
B8ZS
DSX-1, CSU (optional)
DSX-1 to -22.5 dB
100 ohms balanced ± 10 ohms
DB-15F; RJ-48 (Network)
1 - 150 feet (Standard); 0 - 750 feet (Option)
0.0 dB; -7.5 dB; -15.0 dB
AT&T Accunet T1.5
1.344 Mbps (56 Kbps/DS0); 1.536 Mbps (64 Kbps/DS0)
Data Port Interfaces
V.35; RS-422; RS-232C; Switch-selectable EIA control
lines; Compatible with DEC DMR11 (V.54) interface
Voice Connections
3; 6
50-pin Amphenol style
Data Connections
8; 12; 24
25-pin DB-25F
Break-and-test signal monitors for transmit and receive
Non-interruptive signal monitors for transmit and receive
208
