AC - Accessing the CCU/D/I Mux III User Screen

To access the D/I Mux III CCU user sub-menu screen, from the AMCU Main Menu, type AC and press
[Enter]. The screen shown in Figure 4-6 appears.
] ?
08:42:57 ----------------------[ Menu ]----------------------- 11/28/95
ALARMS
DA Display
ZA Clr Cnts SO Set Comm. Rpts
SHELF CONFIGURATION
DC Display
SC Set
MAP TABLE
DT Display DN Disp. Wrking
ST Edit SN Set Wrking
CLOCK SOURCE
DS Display SS Set
PASSWORDS
LO Logout SW Install
DW Display EW Erase
Note: This procedure only applies to D/I Mux III shelves containing AMCU cards.
Chapter 4. Configuration and Operation
SYSTEM PARAMETERS
DP Display
SR Set Comm. Rate
LINE CARDS
DL Display Table
CL Copy Config
MAP MATRIX
DM Display
SM Edit
DIAGNOSTICS
OL Line Card
PERFORMANCE
PM FDL Monitor
DH Alarm History
Figure 4-6. Accessing the CCU/D/I Mux III User Submenu
SP Set
DD Disp Config
SL Set Config
CM Copy
OD T1-CSU
SB Set Error Rate
ZH Clr Alm History
