D/I Mux III User's Manual
SELECT TRAP CRITERIA
By selecting option 8 the AMCU is now told that if a CGA (Carrier Group Alarm) occurs to send a
linkDown Trap to the SNMP Manager.
15:43:53 --------[ Set T1 Line Trap Criteria - T1 One ]-------- 06/19/97
If any alarm marked Check is present, the T1 line will be considered
down. Unmarked alarms are ignored.
------------------------------------------------------------------------
0: Receive Far End LOF (Yellow) ..... [
1: Transmit Far End LOF (Yellow) .... [
2: Receive AIS (Blue) ............... [
3: Transmit AIS (Blue) .............. [
4: Near End Loss Of Frame (Red) ..... [
5: Near End Loss Of Signal .......... [
6: Loopback ......................... [
7: Bypass ........................... [
8: Carrier Group Alarm .............. [Check]
9: Delayed Carrier Group Alarm ...... [
A: Any Alarm
N: None
Q: Quit
------------------------------------------------------------------------
Chose a number to change the state of that alarm, or chose a letter for
the specified action: [Q]
]
]
]
]
]
]
]
]
]
Figure J-3 Trap Criteria Selected
289
Appendix I. Traps and Modem Dial Out Configuration
