Displaying New Port Expander Configuration

After all port expander configuration options are selected, the Alarm Dial Out screen displays
automatically. Each of the options set during configuration are reflected on the terminal screen,
with the Apply Changes "save" option included. If the displayed options are those desired, press
Y and [Enter] to save all configuration settings. If other changes are desired, press N and
[Enter], and all settings will remain as previously set.
Figure J-12 depicts the port expander configuration settings display screen.
16:49:38 ------------[ Alarm Dial Out ]---------- 11/30/96
Port Expander Present
NCC Port
Port
Attention String
Link String
Link Response
Unlink String
Unlink Response
Apply Changes
Y) Yes
N) No
[Y/N] y
** Press Enter to Continue **
: Yes
: 0
: 1
: 1t.r.o.P
: L
: LINK ESTABLISHED
: U
: UNLINK DONE
Figure I-12. Port Expander Configuration Settings Display Screen
