Mm - Modifying/Installing The Manager - Coastcom D/I Mux III System User Manual

MM - Modifying/Installing the Manager

From the AMCU Main Menu, use the MM command to run the Modify/install Manager function, as shown
in Figure 4-29. Refer to Appendix G. SNMP for access option definitions.
The configuration shown in the example below allows an SNMP manager installed on a workstation with
an IP Address of 130.1.10.25 to have Set-and-Get access, and to receive Traps, all with a community
string of "public". By convention, the community string "public" is used when it is not desired that access
be restricted. (The SNMP manager must then be configured to use "public".) If 255.255.255.255 is
entered as an IP Address, an SNMP manager at any IP Address is allowed the specified access.
] MM
Enter Manager IP Address : 130.1.10.25
Access
1) ALL
2) SET/GET
3) GET
4) TRAP
[1] 2
Enter Community String (Up to 15 characters): public
** Manager Set **
]
Chapter 4. Configuration and Operation
Figure 4-29. Modifying/Installing the Manager
128
