Each 50-pin connector has two sets of pins for each line card slot, Channel A and Channel B. 2-
Wire voice cards require the T and R connections. 4-Wire voice cards require T, R, T1, and R1
connections. E&M signalling requires the addition of the E&M connections.
Tables on the following pages give detailed instructions connections appropriate for the 8-, 12-,
and 24-slot D/I Mux III shelf models. Make the connections to the 50-pin connectors according to
Tables 3-9 and 3-10. Table 3-11 shows the color coding for the 50-pin connector. (For more
information on connector pinouts, refer to Appendix E. Wiring and Cable Tables.)
Card Slot
R & T
1 P1 - 1/26
2 P1 - 2/27
3 P1 - 3/28
4 P1 - 4/29
5 P1 - 5/30
6 P1 - 6/31
7 P1 - 7/32
8 P1 - 8/33
9 P1 - 9/34
10 P1 - 10/35
11 P1 - 11/36
12 P1 - 12/37
Chapter 3. Installation
Table 3-9. 50-Pin Connector Pin-Outs
for the 8- and 12-Slot Shelves
Channel A
R1 & T1 M & E
P2 - 1/26 P3 - 1/26
P2 - 2/27 P3 - 2/27
P2 - 3/28 P3 - 3/28
P2 - 4/29 P3 - 4/29
P2 - 5/30 P3 - 5/30
P2 - 6/31 P3 - 6/31
P2 - 7/32 P3 - 7/32
P2 - 8/33 P3 - 8/33
P2 - 9/34 P3 - 9/34
P2 - 10/35 P3 - 10/35
P2 - 11/36 P3 - 11/36
P2 - 12/37 P3 - 12/37
R & T
P1 - 13/38
P1 - 14/39
P1 - 15/40
P1 - 16/41
P1 - 17/42
P1 - 18/43
P1 - 19/44
P1 - 20/45
P1 - 21/46
P1 - 22/47
P1 - 23/48
P1 - 24/49
68
Channel B
R1 & T1 M & E
P2 - 13/38 P3 - 13/38
P2 - 14/39 P3 - 14/39
P2 - 15/40 P3 - 15/40
P2 - 16/41 P3 - 16/41
P2 - 17/42 P3 - 17/42
P2 - 18/43 P3 - 18/43
P2 - 19/44 P3 - 19/44
P2 - 20/45 P3 - 20/45
P2 - 21/46 P3 - 21/46
P2 - 22/47 P3 - 22/47
P2 - 23/48 P3 - 23/48
P2 - 24/49 P3 - 24/49
