Upon selection of one of the displayed options, the system prompts for an indication of whether the A or
B channel is intended for modification. If option 5 is selected, the display in Figure 4-35 appears.
Current Status
Ch. A : Disabled
Ch. B : Disabled
---------------------------------------------------------------
Rx Signalling
A bit
---------------------------------------------------------------
Channel A 0
Channel B 0
* Based on signalling bits and card mode
---------------------------------------------------------------
** Press Enter to Continue **
Selecting options 7 or 8 on the Line Card Diagnostic Menu prompts the screen depicted in Figure 4-36 to
appear.
Current Status
Ch. A: Disabled
Ch. B : Disabled
Transmit Override Status For Ch A:
Set Clear
--- -----
1) 2) Ringback Tone
3) 4) LED
5) 6) Tx Sig.
7) 8) Tx Sig.
9) 2 Wire Output
E) D) Override Status
Q) Quit
Chapter 4. Configuration and Operation
Implemented
B bit Condition *
0 Ringing
0 Ringing
Figure 4-35. Reporting Signaling Bit Status
-------
:
:
Bit A :
Bit B :
:
:
Figure 4-36. Viewing the Channel-A Transmit Override Status
Tx Signalling
A bit B bit
0 1
0 1
Card Status
-----------
OFF
OFF
0
0
Tip Ground
Disabled
134
Detected
Condition*
Idle
Idle
Pending Status
--------------
OFF
OFF
0
0
Ringing
