Displaying New Modem Configuration

After all modem configuration options are selected, the Alarm Dial Out screen displays
automatically. Each of the options set during configuration are reflected on the terminal screen,
with the Apply Changes "save" option included. If the displayed options are those desired, press
Y and [Enter] to save all configuration settings. If other changes are desired, press N and
[Enter], and all settings will remain as previously set. After saving the settings, the screen
prompts to "Press Enter to Continue", after which the Current Mode (for alarm reporting) will
again display.
Figure J-10 depicts the modem configuration settings display screen.
16:49:27 ------------[ Alarm Dial Out ]--------------- 11/30/96
Interval Between Calls : 3 mins
Modem Present
Phone Number
Attention String
Dial String
Hang-up String
Init. String
Apply Changes
Y) Yes
N) No
[Y/N] Y
** Press Enter to Continue **
Current Mode
TERM - NO ALARM REPORTING
: Yes
:
: AT
: Q0DT
: ~~~+++~~~ATH!
: ATE0S0=1Q1V1X4&C0&D0!
Figure I-10. Modem Configuration Settings Display Screen
Last Message Time Out : 20 secs
