DV - Displaying Smart AC Power Supply Parameters

Enter DV to Display the parameters of the 110 Volt Smart AC power supply (P/N 30308-102). Note that
the option to select DV is only available when a Smart AC power supply is installed in the D/I Mux III
system. Figure 4-21 depicts the DV screen.
] DV
10:03:19----------------- [ PS 1 : AC/DC ]----------------- 03/08/95
Minus 12V : -12.1
Minus 5V : - 5.0
Minus 48V : -48.4
SB Fuse : OK
Ringing Generator
-----------------
Voltage
Trip Margin
Frequency
Minor Alarm
Card Type
----------------------------------------------------------------------
AC/DC
----------------------------------------------------------------------
Chapter 4. Configuration and Operation
: 266.8 V[p-p]
: 83.0 V
: 20 Hz
: Enabled
---Hardware---
Part Number Rev
30308-101 B
Figure 4-21. Displaying the Smart AC Power Supply Parameters
Plus 12V : 12.0
Plus 5V : 5.0
Serial
Number
113611-0017
122
Software
Revision
B 9/26/91
