Trending Menus

The Trending Menus allow for setting up and managing onboard
trending of up to 30 data points within the controller . This data
can then be exported to an SD card . The trending memory will
begin over-writing the oldest existing data in the controller's
memory when the allocated trending memory fills up. If an
SD card is installed in the controllers SD card reader slot, an
automatic export of the data will occur every night at midnight .
Table 51: Trending Menu
Item Display
Default Setting
Name
Trending Ena= No
Apply Chgs= No
Sample Time= 300s
TrendOnOff= Off
Export Data= No
Clear Trend= Done
Trending Ena is an adjustable item which enables and
disables the on board trending function .
Apply Changes is an adjustable item which must be set to
make changes to trending point definitions and sampling rate
take effect .
Sample Time is an adjustable item used to the sampling rate
for trending data points .
TrendOnOff is an adjustable item which starts and stops the
on board trending function .
Export Data is an adjustable item which initiates a manual
export of the current on board trend data to an SD card .
Clear Trend is an adjustable item used to either clear only the
current trend data or the entire trend configuration.
OM 920-6 • MICROTECH UNIT CONTROLLER
Password
Range
Level
No
2
Yes
No
2
Yes
1–3600s 2
Off
2
On
No
2
Yes
Done
ClrData 2
ClrCfg

Points 1-8 (Fixed)

The first 8 trending points are fixed and will automatically be trended
when ever the trending function is activated.
Table 52: Points 1-8 (Fixed)
Item Display
Default Setting
Name
Point 1= UnitSt
Point 2= Clg%
Point 3= Htg%
Point 4= SAF%
Point 5= OAD/Eco%
Point 6= CtrlTmp
Point 7= DAT
Point 8= OAT

Points 9-24 (From List)

Trending Points 9 through 16 can be selected from a primary
list of available date points . Trending Points 17 through 24
can be selected from a secondary list of available date points .
See Table 56 on page 76
the primary and secondary listing of points .
Table 53: Points 9-4 (From List)
Item Display
Default Setting
Name
Point 9= None
Point 10= None
Point 11= None
Point 12= None
Point 13= None
Point 14= None
Point 15= None
Point 16= None
Point 17= None
Point 18= None
Point 19= None
Point 20= None
Point 21= None
Point 22= None
Point 23= None
Point 24= None
74
M d
enu esCrIpTIons
Password
Range
UnitSt
Clg%
Htg%
SAF%
OAD/Eco%
CtrlTmp
DAT
OAT
and Table 57 on page 77 for
Password
Range
Primary List
Primary List
Primary List
Primary List
Primary List
Primary List
Primary List
Primary List
Secondary List
Secondary List
Secondary List
Secondary List
Secondary List
Secondary List
Secondary List
Secondary List
www .DaikinApplied .com
Level
2
2
2
2
2
2
2
2
Level
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
2
