Universal I/O Status Menu
The Universal I/O Status Menu provides diagnostic information
to qualified service personnel. The items listed in this menu
will provide current status information of the Universal inputs
and outputs. If the universal I/O is configured for resistance,
the value will be displayed in 1/10th ohm scale . If the I/O is
Table 41: Universal I/O Status Menu
Item Display Name Default Setting
MCB X1= —
MCB X2= —
MCB X3= —
MCB X4= —
MCB X5= —
MCB X6= —
MCB X7= —
MCB X8= —
EMA X1= —
EMA X2= —
EMA X3= —
EMA X4= —
EMA X5= —
EMA X6= —
EMA X7= —
EMA X8= —
EMB X1= —
EMB X2= —
EMB X3= —
EMB X4= —
EMB X5= —
EMB X6= —
EMB X7= —
EMB X8= —
OM 920-6 • MICROTECH UNIT CONTROLLER
Range Password Level
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
configured for mA, the value will be displayed in micro amps
(1 mA = 1000 micro amps). If I/O is configured for voltage, the
value is displayed in 1/1000th volt scale . Example: MCB-X7
(OA Damper analog output) shows a value of 3000, this would
translate into 3 VDC .
Item Display Name Default Setting
EMC X1= —
EMC X2= —
EMC X3= —
EMC X4= —
EMC X5= —
EMC X6= —
EMC X7= —
EMC X8= —
EMD X1= —
EMD X2= —
EMD X3= —
EMD X4= —
EMD X5= —
EMD X6= —
EMD X7= —
EMD X8= —
EME X1= —
EME X2= —
EME X3= —
EME X4= —
EME X5= —
EME X6= —
EME X7= —
EME X8= —
64
M d
enu esCrIpTIons
Range Password Level
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
0–9999999 2
