Commission Unit

Unit Setup

Table 19: Unit Setup Menu
Item Display Name
Apply Changes=
RAT Sensor=
OAT Sensor=
Space Sensor
Eng Units=
Unit Name=
Rapid Start=
Rapid Start Tm=
DO10 Cfg=
100% OA SCU is an adjustable item used to select whether or
not a self contained unit will be configured for 100% outside air
operation .
Space Sensor is an adjustable item to indicate if a space
sensor is connected to the unit controller, or provided via a
network signal .
Eng Units is an adjustable item to indicate if the unit is to
display English or Metric units of measure .

Timer Settings Menu

Table 20: Timer Settings Menu
Item Display Name
Service Time
Start Up
Recirculate
Zero OA Time
Tnt Override
Post Heat
Pwd Timeout
Low DAT
ClgStateDelay
Clg Stg Time
Htg Stg Time
Min Ex Strt Tm
Min Ex Stop Tm
ER Whl Stg Tm
ER Whl Off Tm
Air Flw Ign
Htg Wrmup Tm
Htg Hld Period
Srvc Time Inc
Off HtCl Delay
www .DaikinApplied .com
Default Setting
No
Yes
Yes
Digtl/Net
English
—
No
10 min
FanOp
Unit Name is an adjustable item that allows each controller
to be given a unique name . This may be useful when multiple
units are connected to a single remote HMI .
Rapid Start is an adjustable item that allows the user to select
to initiate a rapid startup sequence at unit power up .
Rapid Start Tm is an adjustable item that allows the user to
set the Rapid Start timing whenever the power is reset to the
controller and the controller finishes its startup sequence.
DO10 Cfg is an adjustable item that redefines the functionality
of the digital output (DO10) on the main control board . The
output is either a supply fan operation indication or a VAV box
signal depending on how this parameter is set .
Default Setting
0 min
180s
180s
0 min
120 min
0s
10 min
6 min
300s
5 min
5 min
120s
120s
5 min
5 min
120s
240s
240s
20s
120s
33
Range
No, Yes
No, Yes
No, Yes
None
Anlog/Net
Digtl/Net
English, SI
—
No, Yes
0–20 min
FanOp
VAVBox
Range
0–240min
1800s
3600s
0–240min
0–300min
0–180s
3–30min
0–60min
0–600s
5–60min
2–60min
60–300s
60–300s
1–100min
1–100min
0–999S
0–999s
0–999s
0–300s
0–999s
