Alarm Configuration

Alarm Limits Menu

The Alarm Limits menu is used to set the limits of the discharge
air temperature sensor and the return air temperature sensor .
Table 33: Alarm Limits Setup Menu
Item Display Name
Hi Disch Temp=
Lo Disch Temp=
Hi Return Temp=
Hi Disch Alm is an adjustable item that sets the high
temperature limit for the DAT sensor . When the discharge air
temperature sensor reaches this set point the unit will go into
the high discharge air alarm .
Lo Disch Alm is an adjustable item that sets the low
temperature limit for the DAT sensor . When the discharge air
temperature sensor reaches this set point the unit will go into
the low discharge air alarm .
Hi Return Alm is an adjustable item that sets the high
temperature limit for the return air temperature . When the RAT
sensor reaches this set point the unit will go into the high return
air temperature alarm .

Alarm Output Config Menu

Table 34: Alarm Out Configuration Setup Menu
Item Display Name
Faults=
Problems=
Warnings=
The digital alarm output indicates the alarm group that contains
the highest priority active alarm . This output is ON when no
alarms are active . The options for the action of this output
when an alarm in a group occurs are ON, Fast Blink, Slow
Blink, or OFF . These can be edited via the keypad/display .
www .DaikinApplied .com
Default Setting
170°F
40°F
120°F
Default Setting
Fast
Slow
OFF
The default values for the three groups of alarms are:
A user could eliminate any signal of a particular group of
alarms through this output by selecting ON for that alarm group
in the keypad/display .
57
Range
90–250°F
-50–50°F
90–150°F
Range
ON
OFF
Fast
Slow
ON
OFF
Fast
Slow
ON
OFF
Fast
Slow
• Warnings - OFF
• Problems - Slow Blink
• Faults - Fast Blink
