Table 36 continued: Manual Control Menu
Item Display Name
GasHtg OnOff=
Htg Valve=
SCR Out=
F&BP Damper=
Htg Stg 1=
SCR Ena 1=
Htg Stg 2=
SCR Ena 2=
Htg Stg 3=
Htg Stg 4=
Htg Stg 5=
Htg Stg 6=
Reheat Valve=
RH Output=
LSCRH Valve=
HGBP Valve=
ERec Wheel=
ER Whl Cmd=
ERBP Dmpr Cl=
ERBP Dmpr Op=
Cond Wtr Pump=
Alm Output=
Fan Op Out=
Manual Ctrl is an adjustable item that puts the unit into manual
control. Major components of the unit are turned on and off by
this control . The units normal control sequences are overridden
in this state with the exception of all the "fault" alarms and the
cooling circuit high pressure and low pressure alarms .
Supply Fan is an adjustable item that turns on the supply fan.
RF/EF is an adjustable item that turns ON the return/exhaust fan.
SAF Spd Cmd is an adjustable item only on VAV units that
sets the speed of the supply air fan .
RF/EF Spd Cmd is an adjustable item for units with VFD
on the return/exhaust fans that sets the speed of the return/
exhaust fan .
OAD/Econo is an adjustable item which is used to set the
economizer damper position .
OAD OpCl is an adjustable item which is used to turn the
OA damper output ON . This output is available only on self
contained units .
OM 920-6 • MICROTECH UNIT CONTROLLER
Default Setting
OFF
0%
0%
0%
OFF
OFF
OFF
OFF
OFF
OFF
OFF
OFF
0%
OFF
0%
OFF
OFF
0%
OFF
OFF
OFF
OFF
OFF
Var Cmp is an adjustable item used in manual control to turn on
the variable speed compressor
Var Cmp Cmd is an adjustable item used in manual control to sets
the speed of the variable speed compressor
VCmp Emg Stop is an adjustable item used in manual control to
test the variable speed compressor Emergency Stop function
Comp 1 OnOff is an adjustable item that turns on compressor #1.
Comp 2 OnOff is an adjustable item that turns on compressor #2.
Comp 3 OnOff is an adjustable item that turns on compressor #3.
Comp 4 OnOff is an adjustable item that turns on compressor #4.
Comp 5 OnOff is an adjustable item that turns on compressor #5.
Comp 6 OnOff is an adjustable item that turns on compressor #6.
Comp 7 OnOff is an adjustable item that turns on compressor #7.
Comp 8 OnOff is an adjustable item that turns on compressor #8.
60
Range
OFF
ON
0–100%
0–100%
0–100%
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
0–100%
OFF
ON
0–100%
OFF
ON
OFF
ON
0–100%
OFF
ON
OFF
ON
OFF
ON
OFF
ON
OFF
ON
M d
enu esCrIpTIons
Password Level
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
4
