Service Menus

Timer Settings Menu

The Timer Settings Menu is also available from the
Commission Unit Menu, and is described on
Save/Restore Menu
The Save/Restore menu can be used to save or restore the
user configured parameters as well as reset the controller back
to the factory default parameters .
Table 37: Save/Restore Menu
Item Display Name
Save Params=
Rstr Params=
Rstr Factory=
SaveToCard=
LoadFromCard
Save Params is an adjustable item used to save the current
parameters and configuration.
Rstr Params is an adjustable item used to restore the current
parameters and configuration.
Rstr Factory is an adjustable item used to restore the factory
parameters and configuration.
Active Alarms Menu
All active alarms as well as the date and time that they were
detected are displayed on the Active Alarm menu . These
alarms are displayed in order of group priority: Faults first,
Problems second, and Warnings last . Within each group,
alarms are displayed in the order that they were detected .
Table 38: Active Alarm Menu
Item Display Name
Active Alm Count=
ClrAlms=
+Alarm 1:Alarm Type
+Alarm 2:Alarm Type
Event Log Menu
The last fifty events (such as variable compressor unloading
events, both detection and return to normal) as well as the
date and times that they were detected are displayed on the
Event Log menu . These events are displayed in the order
that they were detected . The event that was detected most
recently is displayed first. Multiple occurrences of the same
event may appear .
OM 920-6 • MICROTECH UNIT CONTROLLER
page 33
Default Setting
No
No
No
No
No
SaveToCard is an adjustable item used to save the current
parameters and configuration to an SD card.
LoadFromCard is an adjustable item used to restore the
current parameters and configuration from an SD card.
NOTE: The controller will automatically perform a reset when
Default Setting
—
No
—
—
62
Range
No/Yes
No/Yes
No/Yes
No/Yes
No/Yes
the value of Load From Card is changed from No to
Yes and the enter button is pushed .
Range
0–10
No
ClrFlts
ClrPrblms
ClrWrngs
ClrAllAlms
M d
enu esCrIpTIons
Password Level
2
2
2
2
2
Password Level
None
None
None
None
